Parkside WHEEL RIM BRUSH - Handbuch

1 High pressure connection
on the gun side
2 Cap nut
3 Handle
4 Cleaning bristles
Also observe the safety instruction
for your pressure washer.
Pressure washers can be dan-
gerous if used incorrectly. Do
not direct the jet at people, ani-
mals, live electrical equipment or the
equipment itself.
Technical specifications
Rim washing brush
Intake temperature ......max. 60°C / 140°F
Initial Operation
Plug in and twist to connect the rim
washing brush to the spray gun of your
PHD 150 A1 pressure washer via the high
pressure connection on the gun side (1).
Screw the cap nut (2) against the spray
gun for a firm grip.
On sensitive surfaces, test the
cleaning bristles (4) initially on a
location that is not visible, in order
to ensure compatibility.
1 2 3
4
Removal of the rim washing brush is in
the reverse order. Start by loosening the
cap nut (2). Then push and turn the rim
washing brush in the opposite direction to
separate the rim washing brush from the
spray gun.
• Store the equipment in a frost-proof
room.
Guarantee
• The product is not suitable for commer-
cial or professional use.
• Justified guarantee claims should be
reported to our Service Centre (see
cover page for telephone & fax no.s,
and email address). Our Service Team
will tell you more about our complaints
handling procedure.
• Damage due to natural wear and tear,
overload or incorrect use is excluded
from the guarantee.
• Furthermore, the prerequisite for guar-
antee services is that the references
indicated in the operating instructions
regarding cleaning and maintenance
have been adhered to.
• Damage, which has been caused from
material or manufacturing faults, will be
made good free of charge, by replace-
ment delivery or repair.
GB IE
