Lindy IPOWER STRIP LITE 32451 - Handbuch

Technische Daten
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - SECOND EDITION (JAN 2005)
For Commercial Use
Tested to Comply with
FCC Standards
Model
IPower Switch 4 LITE
No. 32450 IPower Switch 8 LITE
No. 32451
Remote Access Port Ethernet 10Base-T, RJ-45
Netzspannung Ein-/Ausgänge 1x IEC-Stecker / 4x IEC-Buchse 2x IEC-Stecker / 8x IEC-Buchse
Eingangsleistung 230VAC 2300VA (10A@230V) 230VAC 2x2300VA, 2x(10A@230V)
Ausgangsleistung Max. 8A pro Anschluss, gesamt 10A Max. 8A pro Anschluss, gesamt 2x10A
Betriebstemperatur +5°C bis 40°C, zum Einsatz in geschlossenen Räumen
Luftfeuchtigkeit 5 bis 85% rel.H. nicht kondensierend
Abmessungen (HXBXT), Gewicht 44,5 (1HE) x 441 x 63 mm, 1,4kg 44,5 x 788 x 63 mm, 2,3kg
European EMC Directive 89/336/EEC CE statement
This equipment complies with the requirement for CE mentioned in the European Directive 89/336/EC and
Standards EN55022 and EN55024.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class B Digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
y Reorient or relocate the receiving antenna
y Increase the separation between the equipment and receiver
y Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
y Consult the dealer or an experienced technician for help
You are cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - SECOND EDITION (JAN 2005)
For Commercial Use
Tested to Comply with
FCC Standards
IPower Strip LITE
Benutzerhandbuch
Deutsch
(Stand 8/2004 Firmware Version 1.18, Änderungen für ausgelieferte Version vorbehalten)
Model 1 IN / 4 OUT: LINDY No. 32450
Model 2 IN / 8 OUT: LINDY No. 32451
