Subminiatursteckverbinder Serie 711
Subminiature connectors series 711
Bestell-Nr.
Ordering-No.
Bezeichnung
Description
Abbildung
Figure
Maßzeichnung
Drawing
Flanschstecker, löten
Male panel mount connector, solder
Flanschstecker, tauchlöten
Male panel mount connector, dip solder
10,2
M 9 x 0,
5
6,7
2,7
5,8
Ø
11
,5/SW 1
0mm
max. Wandstärke: 1,5 mm
max. wall thickness: 1,5 mm
10,2
M 9 x 0,
5
6,7
3
6,1
Ш 0,
6
Ш
11
,5/SW 1
0mm
max. Wandstärke: 1,5 mm
max. wall thickness: 1,5 mm
2 3 4 5 7 8
Technische Daten
Specifications
Polzahl
Steckverbinder Verriegelung
Anschlussart
Anschlussquerschnitt
Kabeldurchlass
Schutzart
Mechanische Lebensdauer
Obere Grenztemperatur
Untere Grenztemperatur
Bemessungsspannung
Bemessungs-Stoßspannung
Verschmutzungsgrad
Überspannungskategorie
Isolierstoffgruppe
Bemessungsstrom (40°C)
Durchgangswiderstand
Material Kontakt
Kontaktoberfläche
Material Kontaktkörper
Material Gehäuse
Number of contacts
Connector locking system
Termination
Wire gauge
Cable outlet
Degree of protection
Mechanical operation
Upper temperature
Lower temperature
Rated voltage
Rated impulse voltage
Pollution degree
Overvoltage categorie
Material group
Rated current (40 °C)
Contact resistance
Material ot contact
Contact plating
Material of contact body
Material of housing
schrauben/screw
löten, tauchlöten/solder, dip solder
max. 0,25 mm
2
(max. AWG 24) / —
max.0,14 mm
2
(max. AWG 26) / —
—
IP40
> 500 Steckzyklen/> 500 mating cycles
+ 85 °C
– 40 °C
125 V
1500 V
1
II
llI
4 A
3 A
1 A
≤ 3 mΩ
CuZn (Messing/brass)
Au (Gold/gold)
PA (UL 94 V-0)
CuZn (Messing vernickelt/brass nickel plated)
Polzahl
Contacts
2
3
4
5
7
8
Bestell-Nr.
Ordering-No.
09 0073 00 02
09 0077 00 03
09 0081 00 04
09 0097 00 05
09 0477 00 07
09 0481 00 08
Polzahl
Contacts
2
3
4
5
7
8
Bestell-Nr.
Ordering-No.
09 0073 20 02
09 0077 20 03
09 0081 20 04
09 0097 20 05
09 0477 22 07
09 0481 22 08
Flanschstecker mit flexibler Leiterplatte
Male panel mount connector with flexible PCB
6,1
6,7
Ø 0,
6
M 9 x 0,
5
3
10,2
Ø
11
,5/SW 1
0mm
max. Wandstärke: 1,5 mm
max. wall thickness: 1,5 mm
Polzahl
Contacts
2
3
4
5
7
8
Bestell-Nr.
Ordering-No.
—
—
—
—
09 0477 65 07
09 0481 65 08
