Configuration
G&D DL-Compact · 16
If a Sun keyboard is connected to the console, the Solaris Shortcut Keys of this key-
board can be used after their support has been activated. Even when using a stan-
dard keyboard, these functions can be carried out by applying the key combinations
listed below:
Selecting the EDID mode of the KVM extender
The EDID information (Extended Display Identification Data) of a monitor inform the
graphics card of a connected computer about different technical device features. The
information are usually transmitted via Enhanced-DDC (Enhanced Display Data Chan-
nel) from KVM extender to the computer without alteration.
A special EDID mode can be activated if the computer connected to the KVM
extender is assembled with a Barco PVS graphics card. This mode considers the spe-
cial treatment of EDID data by the graphics card.
Use the default setting (Auto) when applying another graphics card.
Key combination Solaris Shortcut Key of the Sun keyboard
Ctrl+Alt+F2 Again
Ctrl+Alt+F3 Props
Ctrl+Alt+F4 Undo
Ctrl+Alt+F5 Front
Ctrl+Alt+F6 Copy
Ctrl+Alt+F7 Open
Ctrl+Alt+F8 Paste
Ctrl+Alt+F9 Find
Ctrl+Alt+F10 Cut
Ctrl+Alt+F11 Help
Ctrl+Alt+F12 Mute
Ctrl+Alt+NUM+ Loud
Ctrl+Alt+NUM- Quiet
Ctrl+Alt+NUM* Compose
Ctrl+Alt+Pause Shutdown
Pause+A Stop
IMPORTANT: It might be possible that Barco PVS graphics cards do not create an
image in the Auto mode!
