29 37 Red (8 Bit) 0-100% 000-255
38 Red fine (16 Bit) 0-100% 000-255
30 39 Green (8 Bit) 0-100% 000-255
40 Green fine (16 Bit) 0-100% 000-255
31 41 Blue (8 Bit) 0-100% 000-255
42 Blue fine (16 Bit) 0-100% 000-255
32 43 White (8 Bit) 0-100% 000-255
44 White fine (16 Bit) 0-100% 000-255
}
Pattern RGBW
54
FIXTURE MODE "Standard"
Color mixing
The
A12 features a colour wheel channel, RGBW colour mixing channels and a CTC
channel.
The colour wheel channel has priority. Only if the colour wheel channel is set to
DMX
value 000-001 it is possible to operate the RGB channels. (In Extended mode E8
at
DMX value 001 all LED rings are adapted to the color of the inner ring (A)).
The
CTC channel can be combined with both the RGBW channels and the colour wheel
channel.
The pattern channel
of
the colour wheel channel and one colour with RGBW colour mixing. The patterns will
work
between this two colours.
Control channel 5
The
control channel (channel 5) offers additional control over the RGBW-channels. It is
useful
to adjust the white balance when units are being used in rental business and a
variety
of fixtures are supposed to offer a even colour mixing.
DMX
000-007: No white balance active.
DMX
008-015: Basic adjustment on the RGBW channels. So it‘s possible to have
always the same white from different production series (factory adjustment). Marginal
reduced intensity of the RGBW strings.
DMX
016-023: White balance to 5600K. Reduced intensity in blue. Possible reduction in
intensity of green and red. If fixtures are set to this DMX value the white of fixed colors
and RGBW color mixing is the same, it‘s a white similar to HMI white.
DMX
024-031: White balance same to DMX 016-023. Plus the RGBW curves are
working in linear mode so it is possible to use the color picker function of various
lighting control desks.
Some lighting desks have a delay during DMX refreshing and DMX values get missed
during a fade out or using the fader. That means the A12 with his fast reaction time rate
this happen as a shutter and shows flickering in the beam. To avoid this you can select
5 different modes. Depending on the modus, the reaction time of the A12 gets lower.
(channel 9) provides patterns with the LED rings. Choose one colour
5.3 Important information
