VARYCOLOR 6 MSR 575/2
- 15 -
Stückliste VARYCOLOR 6 575/2MSR Display-Platine
C1 820P
C2 820P
C3 820P
C4 820P
C5 820P
C6 820P
C7 3N3
C8 3N3
C9 100N
C10 100N
C11 100N
C12 100N
C15 100N
C16 100N
C18 100N
C19 100N
C20 100N
C21 100N
C22 100N
C23 100N
C24 100N
C25 100N
C26 100N
C28 47U/25
C29 10U/16
C30 220U/35
C31 220U/35
C32 2200/40
C33 4700U/25
C34 470U/16
C35 3N3
C36 820P
C37 820P
D1 LM336LP
D4 SA5_0CARL
D11 1N4003
D12 FBU4B
D13 FBU4B
F1
FUSE 4A T
F2 FUSE 6,3 A T
IC1 68HC11F1
IC2 27C256
IC3 ADM709LAN
IC4 AM26LS31
IC5 PBM3960
IC6 PBM3960
IC7 PBL3771
IC8 PBL3771
IC9 LS7266R1
IC10 PAL16L8
IC11 ADM483E
IC12 LM317T
IC13 PBL3771
JP1 AMP2
JP2 AMP2
JP3 AMP1
JP4 AMP1
JP5 AMP1
JP6 AMP1
JP7 AMPQuick2
JP8 AMPQuick12
JP9 AMPQuick12
JP10 AMPQuick4
LCD1 LCD1601_B
R1 1K
R2 8R2
R3 Nicht
bestückt
R4 0R
R5 10K
R6 4K7
R7 10K
R8 9*10K
SIP
R9 15K
R10 15K
R11 1K
R12 1K
R13 1K
R14 1K
R15 1R
R16 1R
R17 1R
R18 1R
R19 470R
R20 36R
R24 1K
R31 787R
R32 243R
R33 15K
R34 1R
R35 1R
R36 1K
R37 1K
S1 TASTSK_B
S2 TASTSK_B
S3 TASTSK_B
S4 TASTSK_B
Y1 YO16M
Stückliste VARYCOLOR 6 575/2MSR Effekt-Platine
C1 free
C2 free
C3 free
C4 free
C5 220F/35V
C6 820p
C7 820p
C8 820p C9 820p
C10 820p
C11 820p
C12 820p
