9
CN35 MIDI-Konfigurationsanleitung
MIDI Exclusiv Datenformat
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8th byte 9th byte 10th byte
1 2 3 4 5 6 7 8 9 10
Byte ID Beschreibung
1 F0 Start code
2 40 Kawai ID Nummer
3 00 - 0F MIDI Kanal
4 10, 30 Function Code (30 wenn Multi Timbral On/Off)
5 04 Information, dass es sich um ein Digitalpiano handelt
6 0B Information, dass es sich um das Modell CN handelt
7 data 1
Siehe nachfolgende Tabelle 8 data 2
9 data 3
10 F7 End Code
data 1 data 2 data 3 Funktion
00 00 - Multi-timbre Off
02 00 - Multi-timbre On 1
01 00 - Multi-timbre On 2
0F 15 - 6C - Split Point: A0 - C8
14 00 - 7F - Dual/Split balance
16 1F - 60 - Tune, 40: 440 Hz
17 00, 7F - 00: Program Change Off, 7F: Program Chage On
18 00 - 07 -
00: Light, 01: Normal, 02: Heavy, 03: Off, 04: Light +, 05: Heavy +, 06: User1, 07:
User2
19 00 - 03 - Lower Octave Shift
20 00 - 7F 00 - 7F Dual, data 2: Main sound, data 3: Layer sound
21 00 - 7F 00 - 7F Split, data 2: Upper sound, data 3: Lower sound
22 00 - 7F 00 -7F Four Hands, data2: Right sound, data3: Left sound
25 00 - 09 00 - 0B
data2: Temperament
00: Equal(Stretch Off), 01: Pure Major, 02: Pythagorean, 03: Meantone,
04: Werkmeister, 05: Kirnberger, 06: Equal(Stretch On), 07: Pure Minor,
08: Equal(Piano Only), 09:User,
data3: Key
26 00, 7F 00 - 0F Multi-timbre, data 2: 00 (Mute), 7F (Play), data 3: Channel
27 00 - 02 00 - 02 Dual/Split, Right (Upper)/Left (Lower), sound Bank LSB
