Revox S piccolo - Handbuch (Seite 11)

cube / piccolo Re:sound
9
Positioning the speakers
Your speakers are set up correctly, if
your favourite listening position and
the speakers
form an approximately
equilateral triangle. The speakers
should radiate from an acoustically
hard environment with good
reverberation characteristics into the
more damped part of the listening
area.
The loudspeakers cube and piccolo
of the Re:sound S series are
specially designed for operation on
a sideboard or as a wall-mounted
speaker.
Revox provides ball joint wall
brackets with a wide swivelling
range. The brackets are designed
for one-screw wall-mounting and
attach to the speakers by means of
three screws. For detailed
information on wall-mounting, refer
to the instructions that come with
the wall brackets.
Wall bracket cube: 1.084.454.00
Wall bracket piccolo: 1.084.434.00
The sound radiation should not be
impeded. No objects should be
placed in front of or too near to the
speakers. The listener should be
able to see both speakers
completely.
Please make sure that you do not
put things too close to the
loudspeaker (only Re:sound piccolo),
since part of the sound comes out of
the bass tubes on the rear of your
speakers. Therefore, we recommend
you to leave about one inch of
space behind it.
For best sound quality, position the
speakers at ear level (± 12 in. / ± 30
cm).
Please note that positioning the
speakers opposite large, smooth
walls can cause unpleasant
reflections.
The low frequency behaviour may
be controlled by the distance of the
speakers to the walls. Depending on
the acoustic actualities of your
room, very serious changes of the
bass volume can occur between the
possibilities “larger distance” (slim
bass) and “in the angle of the room”
(beefy bass)’’.
