Connecting the loudspeakers
Important
Before cabling disconnect your hi-fi
system (amplifier, receiver, power
amplifier etc.) from the mains!
Center Loudspeaker
Connect the speaker outputs of your
multichannel amplifier with the label
Center Speaker with the screw
terminals of the Re:sound center 03
with correct polarity.
An invalid polarity results in a very
bad tonal balance up to missing
basses as well as an unclear stereo
image. Use loudspeaker cables with
skinned ends.
Tighten screw terminals fast
because otherwise they can cause
side noise.
Cable Length & Cross Section
Revox loudspeakers have consistent
electrical phase and impedance
characteristics and are an
uncritical load for the power
amplifier and the loudspeaker
cables.
Your specialist dealer offers
loudspeaker cables in diverse styles
and with various cross sections. He
will be glad to advise you according
to your individual needs.
In order to keep cable loss as low
as possible, we suggest the
following cable cross section
dimensioning scheme:
Cable length Dimension
bis 5m / 16ft: 1.5 mm 2 / AWG15
bis 10m / 33ft: 2.5 mm 2 / AWG13
über 10m / 33ft: 4.0 mm 2 / AWG11
We advise against using long
cables (more than 20 m / 65 feet)
because of inevitable loss.
