4
RA-10 Stereo-Vollverstärker
Figure 2: Anschlussdiagramm
RIGHT
INTEGRATED AMPLIFIER
MODEL NO. RA-10
POWER CONSUMPTION : 220W
SERIAL NO. RP-502
SPEAKER B
LEFT RIGHT
CLASS 2 WIRING
LEFT RIGHT
SPEAKER A
12V TRIGGER OUT SPEAKER IMPEDANCE
A OR B - 40HMS MINIMUM
A AND B - 80HMS MININUM PRE OUT TAPE AU X 2 AU X 1 TUNER CD PHONO
IN OUT
LEFT GND
DOUBLE INSULATION When servicing
use only identical replacement parts.
ROTEL
