4. Installation
4.1 Housing Opening
CAUTION: Danger of electric shock. Make sure all power switches have been turned off.
NOTE: Stop loosen the three back cover fixing screws as soon as the back cover gets free. This will prevent the screws from falling as they will be retained
by the gasket.
• Disconnect the earthing cable from the internal slide.
• Slide the body forward and leave it hanging from the external slide.
NOTE: If the body has to be removed, the front cover must be disassembled first.
4.2 Cable Entry
• Loosen the external nut on the cable gland and remove the plug.
• Insert the connecting cables through the M6 cable glands.
CAUTION: Minimum cable diameter 5mm, maximum 10mm.
5
