6 GB/IE
Introduction
Scroll saw PDKS 120 B3
Q Introduction
We congratulate you on the purchase of
your new device. You have chosen a high
quality product. The instructions for use
are part of the product. They contain important in-
formation concerning safety, use and disposal. Be-
fore using the product, please familiarise yourself
with all of the safety information and instructions
for use. Only use the unit as described and for the
specified applications. If you pass the product on
to anyone else, please ensure that you also pass
on all the documentation with it.
Q
Intended purpose
The scroll saw is intended for the intricate cutting of
wood and plastic in a DIY environment (see Fig. F).
Any other uses, and modifications to the appliance,
are deemed to be improper usage and may result
in serious physical injury. The manufacturer accepts
no responsibility for damage(s) resulting from
improper usage.
Q Features and equipment
1 Dust blow tube
2 Stroke rate controller
3 OFF button
4 ON button
5 Angle setting screw
6 Saw table
6 a Angle scale
7 Saw blade
8 Top saw blade mounting
9 Blade guard
10 Knurled nut
10 a Plain washer
10 b Guide plate
10 c Screw
11 Attachment arm
12 3 x feet
13 Clamping lever
14 Bottom blade mounting
Q
Included items
1 x Scroll saw PDKS 120 B3
1 x Blade guard
2 x Knurled nuts
2 x Plain washers
The following pictograms are used in these operating instructions / on the device:
Read instruction manual!
Keep children away from electrical
power tools!
V~
Volt (AC)
Caution – electric shock!
Danger to life!
W
Watts (effective power) For indoor use only!
n
0
No-load stroke rate
Risk of loss of life by electric shock from
damaged mains lead or mains plug!
Observe caution and safety notes!
Wear hearing protection, dust
protection mask, protective glasses
and protective gloves.
Risk of explosion!
Dispose packaging and appliance in
an environmentally-friendly way!
Introduction / General safety advice
