Parkside PSS 250 A1 - Handbuch (Seite 11)

11 GB/IE
Operation General safety advice for electrical power tools / Operation
metals or metal objects left in wood. This can hap-
pen especially if the wood dust has paint particles
on it or is mixed with other chemical substances and
the sanded material is hot after extensive working.
You should therefore avoid overheating of products
being sanded as well as the appliance and always
empty the dust collection box
4 or the dust bag
of the vacuum cleaner before work pauses.
Wear a dust mask!
Vacuuming dust with the dust
collection box
Attach the dust collection box:
Push the dust collection box 4 on to the device.
Remove the dust collection box:
Press the release button(s) 3 and pull the dust
collection box 4 off the device.
NOTE: Always empty the dust collection box 4
in due time and shake any remaining dust out; this
will ensure optimal vacuum performance.
Dust extraction using an external
vacuum extraction device
Connecting:
For vacuum dust removal using a vacuum
cleaner, push the suction hose of a vacuum
cleaner approved for use as a dust extraction
device (e.g. a workshop vacuum cleaner) into
the connection
5 – see Fig. D.
NOTE: If it is necessary to use the reducer
piece
12 , push the reducer piece into the con-
nection 5 .
Removing:
Pull the hose of the dust extraction device off
the connection
5 or off the reducer piece 12 ,
if one is used.
Instructions, tips and tricks
Move the oscillating sander parallel, in flat
circles or alternating between lengthwise and
side-to-side motions.
Do not press down with the oscillating sander.
The sanding sheets become clogged, which re-
duces the sanding performance.
Clean the sanding sheet 9 occasionally with
the vacuum cleaner.
The removal performance and therefore the re-
sult of your work are determined by the correct
selection of the speed and sanding sheet
9 grit.
Never sand different materials with the same
sanding sheet
9 (e.g. wood then metal).
The following table offers some values, which are
for information only and may simplify the selection
of a sanding sheet
9 .
Wood Sanding sheet / Grit
Sanding of wood 40–240
Pre-sanding, e.g. of
rough, unplaned
beams and boards
40, 60
Surface sanding 80, 100, 120
Fine sanding of hard
woods
180, 240
Paints / Lacquers Sanding sheet / Grit
Sanding of paint /
lacquer coats or
base coats such
as filler and
smoothing com-
pound
40–320
Sanding off paint 40, 60
Sanding off primer
coats
80, 100, 120
Final sanding of base
coats before painting
180, 240, 320
