Before first use / First use / Servicing and cleaning General safety advice for electrical power tools / Before first use
Avoid drilling paints containing lead
or other substances hazardous to
health.
Do not drill or abrade materials con-
taining asbestos. Asbestos is a known
carcinogen.
Do not drill moist materials or damp
surfaces.
When working with electrical tools,
hold them firmly in both hands and
make sure that your footing is secure.
Using both your hands to hold electrical tools
ensures safer operation of them.
If the inserted tool jams, switch off the
electrical power tool immediately. Be
prepared for high reaction torques as they may
cause kickback.
Always keep the device clean, dry
and free of oil or grease.
Only handle the electrical tool by means
of the insulated handling surfaces when
you are carrying out jobs where the
insertion tool may come into contact
with hidden power supply lines or its
own power cable. Contact with a live elec-
trical wire also makes metal parts of the electrical
tool live and leads to electric shock.
Keep your workplace clean and tidy.
Mixing materials is particularly dangerous.
Dust from light metals can burn or explode.
Wait until the electrical tool has come
to a standstill before putting it down.
The insertion tool could get caught up in some-
thing and this may lead to control of the electrical
tool being lost.
Q
Caution utility services!
DANGER! Ensure that you do not strike
electrical cables, gas or water pipes when
you are working with the electrical power
tool. Check a wall using a suitable detector before
you drill or cut slots.
Q
Original accessories /
attachments
Use only the accessories and attachments
detailed in the operating instructions.
The use of inserted tools or accessories other than
those recommended in the operating instructions
could lead to you suffering an injury.
Q
Before first use
DANGER OF INJURY!
Switch the device off and pull the plug out of the
mains socket before carrying out any work on the
device.
Q
Attaching the auxiliary handle
NOTE: For safety reasons this tool must always be
used with the auxiliary handle
10 in place.
Turn the wing screw 9 anti-clockwise and swivel
the additional handle 10 into the desired position.
Then tighten the wing screw 9 again.
Q
Using the depth stop
Open the wing screw 9 .
Make sure that the toothing on the depth stop 8
is pointing downwards.
Pull the depth stop 8 out as far as necessary
so that the distance between the tip of the drill
and the tip of the depth stop corresponds to
the desired drilling depth.
Firmly tighten the wing screw 9 .
Q
Inserting tools
Quick-action drill chuck:
Take firm hold of the back casing 3 of the
quick-action drill chuck 1 and turn the front
casing 2 until the tool can be inserted.
Insert the tool.
