20 GB
Commissioning / Maintenance and cleaning / Service centre / Warranty / Disposal Before taking tool into use / Commissioning
The supplied accessories are suitable for the most
widespread areas of application (see Figs. C, D, E,
F and G).
5 Knife / Scraper attachment (offset)
6 Knife / Scraper attachment (straight), e.g. for
removing carpets, felts, cork sheets as well as
plaster and adhesive residues (see Fig. C, E)
7 Spatula attachment (flat), e.g. for removing
paint residues, silicon and foams (see Fig. D)
8 Chisel attachment (flat), e.g. for carving soft
woods (see Fig. F)
9 Carving chisel (13 mm), e.g. for carving in
softwoods (see Fig. G)
Q Changing attachments
Wear suitable protective gloves when
inserting and testing attachments tool 4 .
Notice: The curve / working edge of the attachment
tool
4 must always point downwards.
Inserting a tool attachment:
Push the tool lock 2 forwards to “UNLOCK”.
Insert the attachment tool 4 as far as it will go
in the tool receptor 3 (see Fig. A).
Push the tool lock 2 backwards to “LOCK” -
the tool attachment is locked.
Removing a tool attachment:
Push the tool lock 2 forwards to “UNLOCK”.
Remove the inserted tool attachment 4 from
the tool receptor 3 .
Q
Commissioning
Q
Working Notices
Always work away from the body.
Hold the appliance with both hands (see Fig. B).
Introduce the attachment tool 4 to the material
or the area to be worked with the appliance
switched on. In that the working motion of the
appliance first takes place on contact with the
material, you will achieve a much more accu-
rate positioning of the attachment tool.
Q Switching ON / OFF
Notice: The working motion of the appliance first
takes place on material contact.
Switching on:
Push the ON / OFF switch / Stroke rate prese-
lector
1 forwards.
Switching off:
Push the ON / OFF switch / Stroke rate prese-
lector
1 backwards.
Q Selecting the stroke rate
Note: The optimal stroke rate is dependant on
the material or the surface to be worked. It is best
determined by simple trial and error. Always start
off with the lowest setting. Should the removal be
too slight, increase the stroke rate level for level.
Slide the ON / OFF switch / Stroke rate prese-
lector
1 to the front to increase the stroke rate.
Level 1: low stroke rate for precision work
Level 2: moderate stroke rate
Level 3: highest stroke rate for fast removal
Slide the ON / OFF switch / Stroke rate prese-
lector
1 to the rear to decrease the stroke rate.
Q
Resharpening the
attachment tools
The best work results are only achieved with sharp
attachment tools. You should thus resharpen them
in good time.
RISK OF INJURy! Remove
the plug from the power socket before beginning
to sharpen the tools.
