Parkside PSS 250 A1 - Handbuch (Seite 12)

11 GB/IE
Vacuuming dust with the dust
collection box
Attach the dust collection box:
j Push the dust collection box 4 on to the device.
remove the dust collection box:
j Press the release button(s) 3 and pull the dust
collection box 4 off the device.
NOTE: Always empty the dust collection box 4
in due time and shake any remaining dust out; this
will ensure optimal vacuum performance.
Dust extraction using an external
vacuum extraction device
Connecting:
j For vacuum dust removal using a vacuum
cleaner, push the suction hose of a vacuum
cleaner approved for use as a dust extraction
device (e.g. a workshop vacuum cleaner) into
the connection
5 – see Fig. D.
NOTE: If it is necessary to use the reducer
piece
12 , push the reducer piece into the con-
nection 5 .
removing:
j Pull the hose of the dust extraction device off
the connection
5 or off the reducer piece 12 ,
if one is used.
Q Instructions, tips and tricks
j Move the oscillating sander parallel, in flat
circles or alternating between lengthwise and
side-to-side motions.
j Do not press down with the oscillating sander.
The sanding sheets become clogged, which
reduces the sanding performance.
j Clean the sanding sheet 9 occasionally with
the vacuum cleaner.
j The removal performance and therefore the
result of your work are determined by the correct
selection of the speed and sanding sheet
9 grit.
j Never sand different materials with the same
sanding sheet
9 (e.g. wood then metal).
The following table offers some values, which are
for information only and may simplify the selection
of a sanding sheet
9 .
Wood Sanding sheet / Grit
Sanding of wood 40 - 240
Pre-sanding, e.g. of
rough, unplaned
beams and boards
40, 60
Surface sanding 80, 100, 120
Fine sanding of hard
woods
180, 240
Paints / Lacquers Sanding sheet / Grit
Sanding of paint /
lacquer coats or
base coats such
as filler and
smoothing com-
pound
40 - 320
Sanding off paint 40, 60
Sanding off primer
coats
80, 100, 120
Final sanding of base
coats before painting
180, 240, 320
Q Maintenance and Cleaning
WArNING! DANGEr OF INJUry! Before
performing any work on the appliance, disconnect
the power plug.
j Clean the appliance regularly, preferably always
immediately after use.
j Do not use any sharp objects for cleaning the
appliance. Never permit fluids to permeate
inside the appliance.
j Use a cloth to clean the casing. Never use petrol,
solvents or cleansers that damage plastics.
A vacuum cleaner is required for thorough
cleaning of the appliance.
j Ventilation openings must never be obstructed.
j Remove adhering sanding dust with a brush.
Operation / Maintenance and cleaning
