ply lead and the extension cable for
damage and ageing. Do not use the
equipment if the cable is damaged or
worn.Danger of electric shock hazard.
• If the power cable for this equipment is
damaged, it must be replaced by the
manufacturer, a customer service agent
of the same or a similarly qualified per-
son in order to prevent hazards.
• Switch the machine off and disconnect
the mains plug:
- when the machine is not in use,
- before the machine is opened up,
- for all maintenance and cleaning
work,
- if the connecting cable is damaged
or tangled up.
• Only use replacement parts and acces-
sories delivered and recommended by
our Service Centre. The use of parts by
other manufacturers immediately ren-
ders the guarantee void.
• Do not use the cable to pull the plug
out of the socket. Protect the cable from
heat, oil, and sharp edges.
• Make sure that the mains voltage cor-
responds with the information on the
rating plate.
• Only plug the appliance into a socket
which is safeguarded by at least 13A.
• The device must be connected to a
mains socket via a residual-current
circuit breaker (RCD) with a rated leak-
age current of not more than 30 mA.
The following states how damage
to the appliance and possible in-
jury to people can be avoided:
• Ensure that the machine is correctly
assembled and the filters are in the cor-
rect position.
• Do not use without the filter. This could
damage the machine.
• Only use replacement parts and acces-
sories delivered and recommended by
our Service Centre (see “Replacement
parts/Accessories”). The use of parts
by other manufacturers immediately
renders the guarantee void.
• Only have repairs carried out at our
authorised customer service points.
• Observe the instructions for cleaning
and maintenance of the machine.
• Store the appliance in a dry place and
out of reach of children.
Assembly
Pull out the mains plug.
This will prevent danger of injury
from electric shock.
1. Attach the carrying handle
(2) firmly using the cross-head
screws (2a) supplied.
Ensure that the notches on the
carrying handle go onto the lugs
on the motor head (1) (see small
picture).
2. Attach the feet (7) and secure the
feet using the cross-head screws
(7a) supplied.
3. Insert the filter:
- Foam filter for wet vacuuming
( 15).
- Material filter ( 16) for dry
vacuuming
- Paper filter bag for fine dust
( 17)
Never vacuum without a filter!
4. Place the motor housing (1) on
top of the dirt collector (6) and
close it with the clip (9).
The fastening clips must be
hooked into the snap-in points
provided.
5. Connect the vacuum hose (13)
and the accessories.
