Parkside High-Pressure Extension Hose - Handbuch (Seite 5)

5
Technical specifications
Use the product only as described and for
the applications specified:
Length ............................................. 6 m
Operating pressure / Rated pressure max.
.................................110 bar / 11 MPa
Max. pressure .............160 bar / 16 MPa
Intake temperature ..... max. 60°C / 140°F
Initial Operation
Screw the high pressure connection on the
equipment hose (1) to the high pressure
hose of your pressure washer.
Screw the high pressure connection on the
gun side (2) to the spray gun of your pres-
sure washer.
The high pressure extension hose is an
accessory for PHD 100 A1, PHD 100 B2,
PHD 150, PHD 150 A1, PHD 150 B2,
PHD 150 C2. For use with another device,
the enclosed adapters 3 and 4 may be
helpful.
Be aware of the increased risk of
tripping when using your pressure
washer with the high pressure ex-
tension hose.
Do not run over, squash or crease
the high pressure extension hose.
There is a risk of damage and the-
refore injury to you.
• Store the equipment in a frost-proof
room.
Service-Center
Service Great Britain
Tel.: 0871 5000 720
(£ 0.10/Min.)
E-Mail: [email protected]
IAN 93484
Service Branch
Please note that the following address is
not a service address. Please initially con-
tact the service centre specified above.
DES UK Ltd.
Unit B7
Oxford Street Industrial Park
Vulcan Road
Bilston, West Midlands WV14 7LF
