6 GB/CY
Introduction
Impact drill PSBM 500 A2
Q
Introduction
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the unit as described
and for the specified applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Q
Proper use
The tool is intended for Impact drilling into brick,
concrete and stone as well as drilling into wood,
metal, ceramics and plastic (see Fig. B-E). The clock-
wise / counter clockwise rotation direction switch also
allows the device to be used as a driver. Any other
use or modification to the device shall be considered
as improper use and could give rise to considerable
risk of accident. The manufacturer will not accept li-
ability for loss or damage arising from improper use.
The device is not intended for commercial use.
Q
Features
1 Quick-action drill chuck
2 Front casing
3 Back casing
4 Changeover switch “drill / percussion drill”
5 Locking button for ON / OFF switch
6 ON / OFF switch
7 Rotational direction switch
8 Depth stop
9 Wing screw
10 Additional handle (see Fig. A)
Q
Included items
1 Impact drill PSBM 500 A2
1 Auxiliary handle
1 Depth stop
1 Operating instructions
Q
Technical data
Nom. voltage: 230–240 V∼ 50 Hz
Rated power: 500 W
No-load rotational
speed:
max. 3000 min -1
Percussion rate: max. 48000 min -1
Chuck capacity: max. 13 mm
Drilling in steel: max. ø 10 mm
Drilling in wood: max. ø 20 mm
Drilling in concrete: max. ø 13 mm
Protection class: II /
Noise and vibration data:
Measured values for noise are determined in accor-
dance with EN 60745. The A-weighted noise level
of the electrical power tool are typically:
Sound pressure level: 95.2 dB(A)
Sound power level: 106.2 dB(A)
Uncertainty K:
3 dB
Wear ear protection!
Impact drilling in concrete:
Vibration emission value
a
h, ID
= 12.137 m / s 2
Uncertainty
K = 1.5 m / s
2
Drilling in metal:
Vibration emission value
a
h, D
= 5.237 m / s 2
Uncertainty
K = 1.5 m / s
2
The vibration level specified in
these instructions was measured in accordance with
an EN 60745 standardised measurement process
and can be used to compare equipment. The vibration
Introduction / General safety advice for electrical power tools
