6 GB/IE/CY
Introduction / General safety advice for electrical power tools
Introduction
Modelling and engraving set
PMGS 12 B2
Q
Introduction
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the unit as described
and for the specified applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Q
Proper use
The small drill is to be used for drilling, milling, en-
graving, polishing, cleaning up, grinding, separating
and sawing of wood, metal, plastic, ceramic or stone
in dry rooms. Any other use or modification to the
drill / grinder shall be considered as improper use
and could give rise to considerable dangers. The
manufacturer will not accept liability for loss or
damage arising from improper use. Not intended
for commercial use.
Q
Features and equipment
Small drill:
1
Rotational speed control
2
ON / OFF switch
3
Metal stirrup hanger
4
Plug for mains adapter
5
Clamping nut
6
Spigot nut
7
Spindle lock
Mains adapter (see Fig. A):
8
Plug-in device for plug
4
9
Tray
10
Mains adapter
11
Power cable (with mains plug)
Accessories (see Fig. B):
12
6 HSS drills
13
2 Mandrels for mounting tools
14
3 Polishing wheels
15
4 Grinding wheels
16
1 Metal brush
17
16 Cutting wheels
18
5 Collets
19
2 Plastic brushes
20
3 Milling bits
21
2 Engraving bits
22
5 Grinding bits
23
1 Combination tool
Q
Included items
1 Small drill
1 Mains adapter
1 Plastic case
1 Accessory kit (50-piece)
1 Operating instructions
Q
Technical information
Small drill PMGS 12 B2:
Nominal voltage:
12 V
Nominal input power: 22 W
Idle-running speed:
n
0
5000–20000 min
-1
Drill bit diameter:
max. ø 3.2 mm
Disc:
max. ø 25 mm
Certified acc. to:
EN60745-1; EN60745-2-1
EN60745-2-3
Noise and vibration data:
Measured values for noise are determined in accor-
dance with EN 60745. The A-weighted noise level
of the electrical power tool are typically:
Sound pressure level: 54.70 dB(A)
Sound power level:
65.70 dB(A)
Uncertainty K:
3 dB
Evaluated acceleration, typical:
Hand / arm vibration: 1.868 m / s
2
Uncertainty K = 1.5 m / s
2
