Parkside PHP 500 B2 - Handbuch (Seite 8)

8 GB/IE/CY
Service / Warranty / Disposal Operation / Maintenance and Cleaning / Service
Q
Operation
Q
Before first use
Preparing the glue site:
Do not use inflammable solvents to clean the
glue site.
The ambient temperature and temperature of
the materials to be glued must be not less than
+ 5° C and not warmer than + 50° C.
The glue sites must be clean, dry and free of
grease.
Smooth surfaces should be roughened before
gluing.
Warm any materials that are prone to cool
down quickly (e.g. steel) to improve the bond
with the glue.
Screw on the appropriate nozzle 8 and fit
the wire stand 6 .
Q
Preparing the tool for use
Working with the mains lead connected:
1. Connect the mains lead
11 to the glue gun
connection 10 (see Fig. F).
Insert the mains plug into the mains socket.
2. Fold forward the wire stand 6 .
Stand the device up.
3. Push a glue stick into the feed channel 1 .
4. Let the device heat up for about 5 minutes.
The device is now ready for use.
Cordless working:
1. Connect the mains lead
11 to the charger
connection 3 .
Insert the mains plug into the mains socket.
2. Place the glue gun into the charger 4 .
3. Push a glue stick into the feed channel 1 .
4. Let the device heat up for about 5 minutes.
The device is now ready for use.
5. Repeat the heating-up procedure if the feed
switch becomes stiff or the outcoming glue
becomes viscous.
gluing:
Press the feed clamp 5 to regulate the flow of
glue as required for your work.
1. Apply the glue in individual dots. Apply in zig-
zags on flexible materials such as fabrics.
2. Immediately after applying the glue, press the
two materials together for about 30 seconds. The
glued joint can be loaded after about 5 minutes.
3. When you take a break from work, set the
glue gun down on the wire stand 6 or in the
charger 4 .
4. Remove any glue residue with a sharp knife
after cooling. Glued joints can be loosened
again by applying heat.
Switching off the device:
Pull the mains lead out of the mains socket.
Changing the nozzle:
Wear protective gloves.
Heat up the device for about 5 minutes.
Change the nozzle
8 when it is hot.
DAngeR OF BuRnS!
Touch the nozzle
8 only by the heat shield 9 .
The nozzle tip is hot!
note: Hold item upright, tip up, to prevent glue
from flowing out.
Q
Maintenance and Cleaning
The glue gun is maintenance-free.
WARnIng! Pull the mains lead out of the
mains socket before you clean the tool.
Always keep the device clean and dry.
Do not allow any liquids to enter the tool. Use
a soft cloth to clean the housing. Never use
petrol, solvents or cleaning agents that might
attack plastic.
Q
Service
Have your device
repaired only by qualified specialist
personnel using original manufacturer
parts only. This will ensure that your device
remains safe to use.
If the plug or mains
lead needs to be replaced, always have
