HAMMER DRILL PBH 440 A1
Introduction
Congratulations on the purchase of your
new product. You have decided to purchase
a high-quality product. The operating
instructions are a constituent of this product. They
contain important information with regard to safety,
use and disposal. Before using the product, familiarise
yourself with all operating and safety instructions.
Use this appliance only as described and only for
the specifi ed areas of application. Please also pass
these operating instructions on to any future owner(s).
Intended Usage
The PBH 440 A1 hammer drill (in the following
appliance) is suitable for:
▯ Hammer drilling into brickwork, concrete and
stone
▯ Chiselling into concrete, stone and plaster
▯ Drilling into stone, wood and metal
Any other usage of or modifi cation to the appliance
is deemed to be improper usage and carries the
risk of serious personal injury.
The manufacturer declines to accept responsibility
for damage(s) arising out of usage contrary to the
instructions specifi ed below.
The appliance is not meant for commercial use.
Depicted components
Wing bolt
Right/left rotation switch
On/Off switch
Locking button for ON/OFF switch
Function selector switch
Unlocking button for function selector switch
Additional handle
Tool holder
Locking sleeve
Depth stop
Scope of delivery
1 hammer drill PBH 440 A1
1 additional handle
1 drill chuck with adapter (see fi g. A)
3 drill bits (see fi g. B)
1 fl at chisel (see fi g. B)
1 depth stop
1 carrying case
1 operating manual
Technical details
Nominal power
consumption:
440 W
Rated voltage: 230 V ∼ 50 Hz
Idle speed: n
0
0 - 1.650 / min
Hammer frequency: 0 - 7.500 / min
Impact energy: 1.2 Joules
Drilling capacity: max. 13 mm for steel
max. 24 mm for wood
max. 19 mm for concrete
Protection class: II /
Noise and vibration information:
Noise measurement determined in accordance
with EN 60745 The A-rated noise level of the
electric tool is typically:
Hammer drilling:
Noise level:
84.78 dB(A)
Acoustic power level: 95.78 dB(A)
Uncertainty K: 3 dB
Chiselling:
Noise level:
90.26 dB(A)
Acoustic power level: 101.26 dB(A)
Uncertainty K: 3 dB
Wear hearing protection!
