26 GB
Service centre / Warranty / Disposal Preparing for use / Maintenance and cleaning
Note: Empty the dust collector in good time in or-
der to ensure the optimum removal of
4b dust by
suction.
To do so, remove the dust box 4b from the de-
vice as described above. Open the dust box
by pulling on the tab
4a and remove the cover.
Now tap both parts to thoroughly clean them.
Q Reducer piece
connection:
Push the reducer piece 3 into the adapter
port 2 .
Push the hose of a suitable dust extraction de-
vice approved for that purpose (e.g. a workshop
vacuum cleaner) on to the reducer piece
3 .
Removal:
Pull the dust extraction device hose off the
reducer piece
3 .
Pull off the reducer piece 3 .
Q Attaching / detaching
sanding sheets
Always pull the mains plug is out
of the socket before doing any work on the device.
Attaching:
Sanding sheets are attached to the backing plate
7 by means of the hook and pile fastening.
Detaching:
Simply pull the sanding sheet off the backing
plate
7 (see Fig. C).
Q
Rotating the backing plate
Always pull the mains plug is out
of the socket before doing any work on the device.
Rotate the backing plate 7 into the desired
position (see Fig. D).
Sanding and surfaces:
The sanding output and the quality of the surface
finish are determined by the grade of grit on the
sanding sheet.
Always use sanding sheets with grades that
are suitable for the particular surface you are
sanding.
Q Advice on use
Switch the device on before placing it against
the workpiece.
Apply light sanding pressure only.
Advance the device at an even rate.
Change sanding sheets at the appropriate time.
Do not work on different types of material using
the same sanding sheet (e.g. wood and then
metal). To achieve the best sanding results you
should use unworn, undamaged sanding sheets.
Clean the sanding sheet from time to time with
a vacuum cleaner.
Sand difficult to reach places with the front or
side corners of the backing plate
7 .
Work in parallel and overlapping widths.
After sanding the workpiece, lift the device
from the workpiece before switching it off.
Q
Maintenance and cleaning
Always pull the mains plug is out
of the socket before doing any work on the device.
The delta sander is maintenance-free.
Clean the device frequently. This should be done
immediately after you have finished using it.
For cleaning the housing use a dry cloth only.
Remove any adhering sanding dust with a
narrow paint brush.
Never any kind of sharp object or petrol,
solvents or cleaning agents that might attack
plastic. Do not allow any liquids to enter the
inside of the device.
Always keep the ventilation slots 6 clear.
