GB/IE/CY
- 11 -
8. Grinding wheels are not allowed to be used
without the safety device. The following clea-
rances must not be exceeded:
- Workpiece support/grinding wheel: max.
2 mm
- Safety guard/grinding wheel: max. 2 mm
9. The guard holder, workpiece support and
transparent guard must be fi tted before the
double grinder is used.
10. The power plug must be pulled out before
changing the grinding wheel.
11. The max. circumferential speed of the dry
grinding wheel is: 23.17 m/s
m/s = (d x 3.14 x n) / (60 x 1000)
d = diameter of the grinding wheel in mm
n = motor revolutions per minute
12. Max. permitted motor housing temperature:
80°C
13. Before starting work, fi rmly screw the grinder
to the workbench etc. using the 4 mounting
holes in the base plate.
14. Adjust the spark defl ector periodically in or-
der to compensate the wear of the wheel. Ple-
ase note that the distance between the spark
defl ector and the wheel is to be kept as small
as possible and should in no case exceed
2mm.
15. The grinding wheel must be replaced at
the latest when the spark defl ector and the
workpiece support can no longer be set a
maximum distance of 2mm from the grinding
wheel.
Keep this safety information in a safe
place.
3. Layout and items supplied
3.1 Layout (Fig. 1/3/6/8/11)
1. On/Off switch
2. Safety
glass
3. Spark defl ector
4. Guard hood
5. Grinding wheel
6. Workpiece support star screw
7. Workpiece
support
8. Mounting holes
9. Foot
10. Spark defl ector adjusting screw
11. Grinding /sanding belt
12. Clamp screw for the top belt roller
13. Clamping lever
14. Fastening screw for side cover
15. Belt guidance adjustment screw
3.2 Items supplied
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Important!
The equipment and packaging material
are not toys. Do not let children play with
plastic bags, foils or small parts. There is
a danger of swallowing or suffocating!
•
Original operating instruction
