10 GB/IE
Preparing for use / Maintenance and cleaning / Service centre / Warranty Preparing for use
Q
Preparing for use
CAUTIoN! Make sure that the device is switched
off before you connect it to the mains supply.
Note! Always switch on the delta sander before
bringing it into contact with the workpiece material.
Switching on the device:
Push the ON / OFF switch 8 into Position “ I“.
Switching off the device:
Push the ON / OFF switch 8 into Position “ 0“.
Q Vacuum dust extraction
DANGER oF FIRE! There is
the danger of fire when working with electrical
devices that have a dust box or can be connected
to a vacuum cleaner. Under certain conditions the
wood dust in the dust extraction bag (or in the
vacuum‘s dust bag) may ignite, e.g. as a result of
flying sparks generated when abrading metals or
metal objects left in wood. This can happen partic-
ularly if the wood dust is mixed with paint residue
or other chemicals and the abraded particles are
hot from prolonged abrasion. Therefore you must
empty the device’s dust collection box and the
vacuum cleaner’s dust bag before taking a break
or stopping work and always avoid overheating of
the abraded particles and the device.
Wear a dust mask!
Always pull the mains plug is
out of the socket before doing any work on the
device.
Q
Dust box for internal
vacuum extraction
Mounting:
Slide the dust box for self-generated dust ext-
raction
4b up to the stop on the hand sander.
Removal:
Press the release button 5 of the dust extraction
box for internal vacuum extraction 4b and
withdraw it towards the rear of the device.
Note: Empty the dust collector in good time in or-
der to ensure the optimum removal of
4b dust by
suction.
To do so, remove the dust box 4b from the de-
vice as described above. Open the dust box
by pulling on the tab
4a and remove the cover.
Now tap both parts to thoroughly clean them.
Q Reducer piece
Connection:
Push the reducer piece 3 into the adapter
port 2 .
Push the hose of a suitable dust extraction de-
vice approved for that purpose (e.g. a workshop
vacuum cleaner) on to the reducer piece
3 .
Removal:
Pull the dust extraction device hose off the
reducer piece
3 .
Pull off the reducer piece 3 .
Q
Attaching / detaching
sanding sheets
Always pull the mains plug is out
of the socket before doing any work on the device.
Attaching:
Sanding sheets are attached to the backing plate
7 by means of the hook and pile fastening.
Detaching:
Simply pull the sanding sheet off the backing
plate
7 (see Fig. C).
Q
Rotating the backing plate
Always pull the mains plug is out
of the socket before doing any work on the device.
