Preparing for use General safety advice for electrical power tools / Preparing for use
Push the planing debris removal port 3 into
the device.
Lock the planing debris removal port 3 by
turning it into the “Lock” position.
External vacuum extraction:
If necessary fit the reducer piece
15 when using
a dust extraction system, e.g. a workshop dust
extraction system.
The vacuum cleaner / dust extraction device used
must be suitable for the material being planed.
Connection:
Place the reducer piece 15 firmly on to the
planing debris removal port 3 .
Push the hose of a suitable dust extraction device
approved for that purpose (e.g. a workshop
vacuum cleaner) on to the planing debris remov-
al port
3 or the reducer piece 15 .
Removal:
Pull the hose of the dust extraction device off
the planing debris removal port
3 or off the
reducer piece 15 .
Pull off the reducer piece 15 , if fitted.
Q
Parking shoe (see Figs. B / C)
The parking shoe 16 allows you to lay the device
down without the risk of damaging the workpiece.
When planing, the parking shoe
16 swings up and
exposes the rear part of the sole 9 .
Q
The planing process
CAUTION! DANGER OF KICKBACK!
Always switch on the device before placing it
against the workpiece.
Set the required cutting depth.
Switch on the device.
Always place the front part of the sole 9 down
first on to the workpiece.
Guide the device with even forward movement
over the surface being planed.
Move the device forward at a slow rate and
ensure that the contact pressure acts evenly on
the sole 9 . Moving forward at too great a rate
results in a poorer surface quality and can lead
to blocking of the planing debris removal port.
Q
Chamfering edges (see Fig. H)
The V-grooves 10 in the front sole 9 allow the device
to be used for simple chamfering of workpiece edges.
Use the V-groove most appropriate to your
desired chamfer width.
Place the planer with the V-groove 10 on the work-
piece edge and guide the planer along the edge.
Q
Using the guide fence (see Fig. I)
Attach the guide fence 6 to the device with
the fixing screw 7 .
Release the fixing nut 8 and set the guide at
the desired distance.
Retighten the fixing nut 8 .
Exert some slight sideways pressure when guid-
ing the planer with the guide fence.
Q
Using the rebate depth stop
(see Fig. J)
Attach the rebate depth stop 12 to the device
with the fixing screw 11 .
Set the desired rebate depth with the rebate
depth stop
12 .
Make the required number of passes with the
planer until desired rebate depth is achieved.
Q
Removing and installing a
planer blade
20
(see Fig. D)
DANGER OF INJURY!
Before you carry out any work on the device always
pull the mains plug out of the mains socket.
CAUTION! The sharp cutting edges of the plan-
er blade
20 present an injury hazard! Never
touch the cutting edges of the planer blade 20 .
