Parkside PNTS 1400 D1 - Handbuch (Seite 6)

6
GB IE CY
Overview
Housing
1 Bow handle
2 Bow handle tie bars
3 Motor housing
4 Carry handle
5 Mains lead
6 On/off switch
7 Vent holes
8 Suction connection
9 Stainless steel container
10 Drainage outlet
11 4 steering castors
12 Anti-static chain (not visible)
13 4 accessory holders
14 Locking lever
15 Blow connection
16 2 Mounts in the handle
Accessories
17 Telescopic suction pipe
18 Vacuum tube holder
19 Suction hose
20 Handle with air regulation
Filter
21 Foam filter for wet vacuuming
22 Filter cover
23 Fluted filter for dry vacuuming
24 Paper filter bag for vacuuming
both large and small dirt particles
Nozzles
25 Switchable household nozzle
for vacuuming carpets
for vacuuming smooth surfaces
26 Crevice nozzle
27 Filter basket
Technical data
Rated voltage ........... 230-240 V~, 50 Hz
Rated power input
(Power consumption) ...................1400 W
Cable length.....................................4 m
Safety class ...................................... II
Protection category...........................IP24
Suction force ..............16 kPA (160 mbar)
Stainless steel container capacity
brutto.................................. approx. 23 l
useful volume ....................... approx. 15 l
Weight (incl. all accessories) ..........7.7 kg
Technical and visual modifications may
be carried out due to further development
without prior notice. All dimensions, infor-
mation and statements provided in these
Operating Instructions are therefore subject
to amendment. Legal claims which are
based on the Operating Instructions can
therefore not be recognised.
Safety information
Symbols used in the
instructions
Hazard symbols with in-
formation on prevention of
personal injury and property
damage.
Precaution symbol with information
on prevention of harm / damage.
Notice symbol with information on
how to handle the device properly.
