11
GB IE CY
Assemble/set work-
piece supports
1. Screw the workpiece supports
(6/18) on to the device.
2 positions (see A + B) are
possible for the tape loop.
2. To do so, use the screws
(5a/17a), washers (5b/17b),
toothed lock washer (5c/17c)
and star grip nuts (5/17) pro-
vided.
3. Set the workpiece support of the
grinding belt (19) with the star
grip nut (17) so that the distance
between the grinding belt (19)
and the workpiece support is
max. 2 mm (see small image).
Periodically readjust the workpiece
support in order to offset the wear
and tear of the grinding disc (dis-
tance max. 2 mm).
Screw device on to work-
bench
Screw the device onto the work-
bench with 4 screws and nuts.
Insert the screws through the 4 bore
holes (13) on the base of the de-
vice.
The screws and nuts required for as-
sembly are not part of the scope of
delivery.
Operation
Caution! Risk of injury!
- Always disconnect the plug from
the mains socket before working.
- Use only grinding disks and acces-
sories recommended by the manu-
facturer. The use of other insertion
tools and other accessories may
cause risk of injury.
- Only use grinding tools which
bear information about the manu-
facturer, type of binding, dimen-
sion and permitted number of
revolutions.
- Only use grinding discs where
the printed rotational speed is at
least as high as what has been
specified on the name plate of
the device.
- Do not use broken, cracked or oth-
erwise damaged grinding disks.
- Never operate the device without
the visual protection disk.
- Always inspect the grinding disc
before starting the device:
Check the distance between the
spark protection and grinding
disc as well as workpiece support
and grinding disc (distance maxi-
mum 2 mm).
- The grinding disc must be re-
placed once the spark protection
and workpiece support on the
grinding disc do not have dis-
tance of max. 2 mm.
- Switch on the equipment only
when it is safely installed on the
work surface.
Keep your hands away from
the grinding disc and grind-
ing belt when the device is in
operation. Injury hazard!
