21 PDSP 1000 B2
GB
Mount the collecting bag for sand-
blasting material
■ Use a screwdriver to attach the collecting bag
to the appliance with the supplied screw
clip .
Select and fi tting attachments
■ Start by selecting the appropriate attachment
for the job at hand ( , , , ).
■ Push the selected attachment fi rmly onto the jet
nozzle , ensuring that no air can escape from
the sides.
Using the compressed air sand-
blaster gun
■ Carefully prepare the workpiece that is to be
blasted. Clean it if need be.
NOTE
► Layers of dust or fat will signifi cantly impair
the results.
■ Carefully cover or mask everything that is not to
be blasted.
■ The distance between the attachment and the
surface being worked plays an important role
and should be kept as low as possible so that
the blasting medium can be collected by the
collecting .
■ The nearer you are to the workpiece, the smaller
the dispersion pattern and vice versa.
■ Do a test run on an old workpiece to fi nd out
the correct distance/working pressure and avoid
excessive refl ection from your workpiece.
Switching on:
■ Set the control dial to "1" to open the air
outlet.
■ Move the compressed air sandblaster close
to the area to be worked.
■ Press the trigger to start operating the com-
pressed air sandblaster gun .
Switching off :
■ Release the trigger to switch off of the com-
pressed air sandblaster gun .
■ Set the control dial to "0" to close the air
outlet.
■ Disconnect the appliance from the compressed
air source after you fi nish work.
NOTE
► First detach the hose from the compressed air
source before disconnecting the supply hose
from the appliance.
In this way you avoid uncontrollable thrashing
about of the supply hose.
Collecting bag for sandblasting
material
NOTE
► Do not re-use surplus sand-blasting material
from the collecting bag until it has been
cleaned.
■ You can remove the surplus sand-blasting material
that has collected in the collecting bag via
the zip fastener or use a screwdriver to undo
the screw clamp and remove the collecting
bag from the appliance.
