HAMMER DRILL PBH 1500 A1
Introduction
Congratulations on the purchase of your
new appliance. You have selected a
high-quality product. The operating
instructions are part of this product. They contain
important information about safety, use and disposal.
Before using the product, familiarise yourself with
all operating and safety instructions. Use this product
only as described and only for the specifi ed areas
of application. Please also pass these operating
instructions on to any future owner(s).
Proper use
The PBH 1500 A1 hammer drill (hereinafter
appliance) is suitable for:
▯ Hammer-drilling into brickwork, concrete and
stone
▯ Chiselling into concrete, stone and plaster
▯ Drilling into stone, wood and metal
Any other usage of or modifi cation to the appliance
is deemed to be improper usage and carries the
risk of serious personal injury.
The manufacturer accepts no responsibility for
damage(s) arising out of usage contrary to the
instructions specifi ed below.
The appliance is not meant for commercial use.
Depicted components
Function selector
Function selector release switch
On/off switch
Hammer switch
Rotational speed preselector adjusting wheel
Additional handle
Tool holder with dust protector cap
Locking collar
Wing screw
Depth stop
Wheel-rim chuck
Chuck key
Package contents
1 hammer drill PBH 1500 A1
1 additional handle
3 drill bits (see fi g. B)
1 fl at chisel (see fi g. B)
1 pointed chisel (see fi g. B)
1 depth stop
1 wheel-rim chuck (see fi g. A)
1 chuck key (see fi g. A)
1 carrying case
1 operating manual
Technical details
Nominal power
consumption:
1500 W
Rated voltage: 230 - 240 V ∼ 50 Hz
Idle speed: n
0
0–750 / min
Hammer frequency: 0–3900 / min
Drilling capacity: max. 13 mm for steel
max. 40 mm for wood
max. 32 mm for concrete
Protection class: II /
Noise and vibration data:
Noise measurement determined in accableance
with EN 60745. The A-rated noise level of the
tool is typically:
Hammer drilling:
Sound pressure level:
85.61 dB(A)
Sound power level: 96.61 dB(A)
Uncertainty K: 3 dB
Chiselling:
Sound pressure level:
94.31 dB(A)
Uncertainty K: 3 dB
Sound power level: 102.31 dB(A)
Uncertainty K: 2.83 dB
