26 GB
Introduction / General power tool safety warnings Introduction
Wall chaser PMNF 1350 A1
Introduction
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the unit as described
and for the specified applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Intended use
The wall chaser (normative cut-off machine), in the
following also referred to as device, in conjunction
with an approved industrial dust extractor, is intended
to cut or slit primarily mineral materials, e.g. concrete
or masonry when firmly applied with the guide sled
without the use of water. Any other uses, and / or
modifications to the appliance, are deemed to be
improper usage and may result in serious physical
injury. Not for commercial applications.
Device description
(see Fig. A–D)
1 ON- / OFF-switch
2 Handle
3 Dust extraction adapter
3 a Union nut
4 Protective cover
5 Adapter flange (with thread)
6 Depth stop set screw
7 Depth stop
8 Additional handle
9 Switch lock
10 Spindle lock
11 Roller
12 Reducer
13 Centring flange
14 Spacers
15 Face pin wrench
16 Chisel
Scope of delivery
1 Wall chaser
2 Cutting discs (preinstalled)
1 Face pin wrench
1 Extraction adapter (preinstalled)
1 Reducer
(for use with the extraction adapter and a size
∅ 32 mm vacuum hose)
1 Chisel
1 Instructions for use
Technical Data
Mains voltage: 230 V∼ 50 Hz
Power input: 1350 W
Rated no load speed: 9000 min -1
Disc ø: 125 mm
Mounting hole: 22.2 mm
Groove depth: 0–30 mm
Groove width: 8–26 mm
Thread: M14
Protection class:
II /
Weight: approx. 4.05 kg
Noise and vibration
Noise and vibration ratings were determined
according to EN 60745.
Noise level L
pA
: 97.6 dB(A)
Uncertainty K
pA
: 3 dB
Sound power level L
WA
: 108.6 dB(A)
Uncertainty K
WA
: 3 dB
Wear ear protection.
Exposure to noise can cause hearing loss.
The total vibration (vector sum of three directions) is
calculated in accordance with EN 60745.
Declaration of vibration emission value
(Cutting concrete slab):
Main Handle: 6.417 m / s
2
Auxiliary Handle: 4.258 m / s 2
Uncertainty K = 1.5 m / s 2
