11 GB/IE
General power tool safety warnings / Start-up / Operation General power tool safety warnings
Original accessories / tools
Use only the accessories and attachments de-
tailed in the operating instructions, or those which
are compatible with the device.
Start-up
Setting the groove depth
Loosen set screw 6 .
Set the depth stop 7 to the desired depth.
Tighten set screw 6 .
Installing the dust
extraction adapter
Slide the pegs of the extraction adapter 3
into the slots of the dust extraction connection.
Turn the extraction adapter 3 to lock.
Loosen union nut 3 a .
Insert the tube of the extraction unit far enough
into the opening on the union nut 3 a .
Tighten union nut 3 a .
Operation
Switching ON / OFF
NOTE: Always switch on the device before bringing
into contact with the material and only then apply
the device to the work piece. The wall grinder fea-
tures electronic smooth start-up. The motor‘s start-up
is delayed.
Switching the unit on:
Activate the switch lock 9 (see Fig. C). Then
press the ON / OFF switch 1 .
Switching the device off:
Release the ON / OFF switch 1 .
Installing and adjusting
the cutting width of the
diamond cutting discs
Loosen set screw 6 .
Slide the depth stop 7 up.
Press and hold the spindle lock 10 .
Use the face pin wrench 15 to loosen the
adapter flange 5 .
Remove the adapter flange 5 .
Set the desired cutting width with the number
of spacers
14 . Be sure to use the centring
flange 13 as the top spacer.
NOTE: You may choose from various spacers.
Please note, the total number of spacers between
the cutting discs and the thickness of the cutting
discs yield the groove width.
Tighten the adapter flange with the face pin
wrench
15 . When doing so, hold the spindle
lock.
NOTE: When setting a cutting width smaller
than the maximum, you must use the spacers
on the clamping collar side, as the clamping
collar alone cannot secure the discs due to the
thread length on the spindle (see. Fig. D).
NOTE: Always replace diamond cutting discs
in pairs.
Handling the wall chaser
(see Fig. E)
ATTENTION! This device is only suitable for
dry cuts!
Use a cable detector to check walls for hidden
electrical-, gas- and water lines before using
the wall chaser.
Select the desired groove width.
Apply the roller 11 of the device onto the brick
wall.
Now switch on the device and immerse into
the brick wall until the depth stop
7 touches.
Now cut the groove into the brick wall, noting
the cutting direction. The device must be rotat-
ing in the opposite direction. The device can
otherwise erratically be pushed out of the cut.
