9 GB/IE
General safety instructions
for compressed air
water jets
Never point the device at yourself, other per-
sons or animals. The water leaves the device at
high pressure and speed. This could present a
major hazard.
Preparations for use
Connecting garden and
compressed air hoses
Wear your protective clothing and put on your
safety goggles! Otherwise there is a risk of injury.
Connect your garden hose to the water con-
nection 3 of the device.
Note: At this point, the device is equipped
with a common click-plug-in system.
If you cannot simply press the hose onto the
connection, please check the compatibility of
the connections.
Never attempt to join the two connections using
excessive force. You will be certain to cause
damage.
Use a ¼” plug-in coupling to connect the com-
pressed air hose to the compressed air supply 1 .
Ensure at all times that the compressed air hose
does not handicap you in your work.
Operating the water supply
Open the main water supply.
Briefly activate the extractor
2 on the device.
The water leaves the device at high speed.
Only tighten the extractor partially 2 to regu-
late the air flow and the water quantity leaving
the device.
Vary the water jet by turning the nozzle to the
right or to the left (see fig. B).
Note: You can change the pressure of your
compressor as you wish to adapt it to the cur-
rent requirements.
However, note that the force of the water jet
will be immense if you increase the pressure of
the compressor considerably.
Ensure that you cause no damage by directly
the jet at unstable material.
Never point the device at yourself, other per-
sons or animals.
After initial use
Once the task has been finished the device must be
disconnect from the compressed air supply
1 .
Briefly activate the extractor 2 on the device
to release any compressed air remaining in the
device.
Now pull back the safety mechanism of the con-
nection coupling on your compressed air hose.
Now release the hose.
Be careful when putting down
the device. Always put down the device Always
put down the device so it does not come into
contact with the extractor
2 . This could poten-
tially result in accidental activation of the device,
which again could result in hazards.
Cleaning and Care
Loosen the compressed air connection.
Clean the device with a lightly moistened cloth.
Do not use corrosive or aggressive cleaning
agents.
Information about warranty
and service processing
Creative Marketing
Consulting GmbH warranty
Dear customer, the warranty for this device is 3 years
from the date of purchase. In the event of product
defects you have legal rights against the retailer of
this product. Your statutory rights are not limited in
any way by our warranty detailed below.
