10 GB/IE/CY
Adjust the shoe 5 to suit the cutting depth.
To do this release the shoe adjustment lever 8
and place the shoe 5 in appropriate position.
Lock the shoe in this position by pulling the
shoe adjustment lever
8 tight.
Q Setting the blade speed
With the oscillation speed setting wheel 1 you can
chose the desired stroke rate (- = lower stroke rate,
+ = higher stroke rate).
The stroke setting can also be changed during op-
eration.
Q Preparing for use
Q Switching on and off
When operating the device you can select between
intermittent or continuous operation mode.
To switch on intermittent operation mode:
Press the ON / OFF switch 3 .
To switch off intermittent operation mode:
Release the ON / OFF switch 3 .
To switch on continuous operation mode:
Press the ON / OFF switch 3 and fix it in the
pressed position with the lock button 2 .
To switch off continuous operation mode:
Press the ON / OFF switch 3 and release it
again.
Q
Guiding the sabre saw
safely and accurately
The shoe 5 pivots to adjust to the workpiece and
provides safe support to the device. It must always
lie against the workpiece when the device is in use.
Q Advice about ways of
working when sawing
Before sawing, check the workpiece for foreign
bodies such as nails, screws etc. and remove them.
Do not allow the ventilation slots to become
covered.
Switch the device on first and only then bring it
into contact with the workpiece.
If the saw blade jams, switch off the device im-
mediately.
Open the sawn gap in the workpiece slightly
using a suitable tool and extract the saw blade.
Always make sure the saw blade type and the
blade oscillation speed are suitable for the
workpiece material.
There are different saw blades available in var-
ious lengths designed to ensure optimum perfor-
mance of every sawing task with your sabre saw.
Saw the material using a steady forward rate
of progress.
Flush sawing:
Using flexible saw blades of adequate length you
can trim off projecting workpieces, such as pipes,
directly at the face of a wall.
Follow these steps:
1. Place the saw blade directly on the wall surface.
2. Bend the blade by applying sideways pressure
so that the shoe 5 comes up against the wall.
3. Switch on the device as described above and
trim the workpiece using constant pressure.
Plunge sawing:
CAUTIoN! DANGER oF KICKBACK!
Plunge sawing can be used only in soft materials
(such as wood etc.).
Follow these steps:
1. Place the sabre saw with the underside of the
shoe 5 against the workpiece.
Switch on the device.
2. Tilt the sabre saw forward and plunge the saw
blade into the workpiece.
