14 GB/IE/CY
Service / Warranty / Disposal Start-up / Maintenance and Cleaning / Service
3. Hold the machine as shown in Figure A and
cut with light pressure.
Types of saw blades:
The saw blades included cover the most common
types of application.
HW Circular saw blade 20 Z85 / 30:
Description: ø 85 mm, 30 HW-teeth
Suitable for: Soft wood, hard wood, boards of any
type, plastics
Diamond cutting disc 21 Z85VR:
Description: ø 85 mm, without teeth
Suitable for: Ceramics, plastics
HS Circular saw blade 22 Z85 / 36:
Description: ø 85 mm, 36 teeth – tooth setting
left / right
Suitable for: Soft wood, soft metals such as aluminium,
copper, plastics
Marking cutting length
Orient yourself at the markings for the cutting
length
8 , in order to check where your cut
starts and ends.
Marking cutting line
The cutting line viewing window allows precise
guidance of the machine along the cutting line
applied to the workpiece.
In order to achieve an exact cut, place the
machine on the workpiece so that the cutting
length labelling appears in the cutting line
viewing window
12 , as depicted in Illustration B.
Connecting the saw
dust extraction
Push the extraction air hose 19 onto the connec-
tion for dust extraction 14 .
Connect a vacuum device approved for the
extraction of sawdust and splinters to the dust
extraction hose
19 .
Replacing the saw blade
1. Operate the spindle lock 13 and loosen the
clamping screw 18 with the Allen key (to open
turn clockwise). Now lift off the clamping screw
and washer
18 and the clamping flange 17
(see also Fig.D).
2. Adjust cutting depth to the maximum position.
3. Swing the base plate
9 upwards.
4. Take off the saw blade.
5. Refitting of the saw blade is the reversal of the
removal.
6. Operate the spindle lock 13 (until it clicks into
place) and, using the Allen key, tighten the
clamping screw
18 .
The arrow on the saw blade must coincide with
the arrow for the direction of rotation
(marked on the appliance).
Maintenance and Cleaning
DANGER OF INJURY! Re-
move the mains plug from the mains socket before
you carry out any work on the appliance.
Clean the appliance after finishing work.
To clean the appliance, use a cloth and do not
use petrol, solvents or cleaning fluids.
Service
Have your appliance
repaired by qualified specialist per-
sonnel using OEM parts only. This ensures
that the safety of the device is maintained.
If the plug or mains
lead needs to be replaced, always
have the replacement carried out by the
manufacturer or its service centre. This en-
sures that the safety of the device is maintained.
