Parkside PHLG 2000 C2 - Handbuch (Seite 8)

8 GB/IE/CY
Q Operation
Q Preparing the device for use
CAUTIOn! When using the device, never
allow the ventilation slots to be covered.
CAUTIOn! DAnGeR OF bURnS! Do not
touch the hot nozzle.
Switching on the device:
Press the ON / OFF switch 2 into setting “I“
or “II“.
Switching off the device:
Press the ON / OFF switch 2 into setting “0“.
Adjusting the air quantity and temperature:
You can use the temperature and air quantity control
2 to set two different blower levels. It is therefore
possible to select the appropriate quantity of air and
temperature in accordance with the intended use:
Setting I 300 l / min 350 °C
Setting II 500 l / min 550 °C
Use as free-standing unit / during
cooling (see Ill. D):
Always set the device down upright on
a level surface, this will allow
· you to have both hands free.
· the device to cool.
Q
Changing the nozzle
Too much heat causes paints
and plastics to ignite.
CAUTIOn! Do not inhale the resulting vapours.
Protector nozzle 4 – for removing paint
and varnish (see Ill. b):
Place the protector nozzle 4 on the outlet
tube 3 .
The spatula shape of the nozzle ensures the air
is properly directed. Use a separate spatula for
removing paint or varnish.
Flat nozzle 5 – for detaching glues,
softening paint (see Ill. C):
Place the flat nozzle 5 on the outlet tube 3 .
Do not apply heat for too long a period, as
burnt paint becomes much more difficult to
remove. Many glues can be softened by warm-
ing. Glued connections can then be detached
and excess glue removed.
Reducing nozzle 6 – for welding plastic:
Place the reducer nozzle 6 on the
outlet tube 3 .
Use the reducing nozzle 6 for heat-shrinkable
sleeves and film.
Q Further examples of uses in
the house, car and garden
Defrosting water pipes:
notice! It must not be used for thawing PVC pipes.
notice! It is often very difficult to tell the difference
between gas pipes and water pipes. If in doubt, ask
a competent person.
notice! Copper pipes are joined using tin solder
and must not be heated above 200 °C.
Loosening a threaded connection:
Heating the threaded connection carefully can
often allow the connection to be released.
Removing weeds:
The heat dries out the weeds and microorganisms.
Lighting barbecue charcoal (see Ill. e):
Do not use methylated alcohol.
Push the barbecue lighting nozzle 7 on to the
hot air nozzle 3 .
Charcoal ignites in a few minutes.
Wax removal:
You can remove wax residues from skis / snow-
board or from candle holders. Use the amount
of care appropriate to the product.
Cleaning / Service / Warranty / Disposal Operation
