9
GB/IE/CY
Before use / Operation / Maintenance and Cleaning
General power tool safety warnings / Safety notes for paint and mortar mixer
Before use
Always pull the mains plug before executing
settings on the device.
Mounting the agitator (see Ill. A)
Firmly screw the shaft
7 b
to the mixing spiral
7 a
.
Subsequently, screw the agitator
7
into the
agitator shaft with the M-14 inner threading
4
.
Secure the chuck with an open-end spanner
2
and tighten the stirrer
7
with a second open-
end spanner
2
.
Dismantling the agitator
To remove the agitator, repeat the process in
the reverse order.
Installing the support bracket
Install the support bracket
3
by securing the
four included crosshead screws in the designat-
ed location on the handle (see Fig. C).
Using the support bracket
Use the support bracket
3
to hang the device
or to set it on the ground. This will prevent it
from dirtying.
Operation
Turning the device ON / OFF
(see Ill. B)
Switching on:
Press the ON / OFF switch
5
.
Switching off:
Release the ON / OFF switch
5
.
Switching on permanent operation:
Secure ON / OFF switch
5
with hold-to-run
button
6
.
Switching off permanent operation:
Press ON / OFF switch
5
quickly.
Setting the speed (see Ill. B)
Note: The ON / OFF switch
5
has a variable
speed control.
Note: The speed cannot be adjusted in non-stop
operation.
Press the ON / OFF switch
5
lighlty to reduce
the speed.
Increase the pressure to increase the speed.
Working with the mixer
Submerge the mixer in the mixture at a low
speed.
After the agitator has been submerged com-
pletely, you may increase the speed.
During the mixing process, move the agitator
around the mixing vessel and mix the mixture
until it is completely processed.
Maintenance and Cleaning
DANGER OF INJURY! Pull
the mains plug out of the mains socket before you
carry out any task on the device.
Cleaning
Use a dry cloth to clean the casing. Under no
circumstances should you use petrol, solvents
or cleaning agents, which may be aggressive
to the plastic.
Always keep the device clean, dry and free of
oil or grease. Do not allow liquids to enter the
interior of the paint and mortar mixer.
Clean the paint and mortar mixer regularly,
preferably immediately after finishing your work.
