11
CY IE GB
Grinding with the grinding
disc
Sharpening drills
Drills with a diameter of 3-10 mm can be
sharpened.
1. Mount the selected sharpener
(see Mounting sharpener).
2. Remove the drill holder (14) from
the sharpener.
3. Insert the drill into the drill holder
(14).
4. Insert the drill holder (14) into
the adjusting device (15).
5. Push the drill to the front into the
V-nut up to the metal stop. The
cutting edges of the drill must fit
closely to the metal surfaces.
6. Using the knurled nut fasten the
drill for drill-fastening (12).
7. Remove the drill holder (14) and
insert it into the rotatable drill
mount (11).
8. Check the alignment of the drill.
The cutting edges of the drill
must be touching the grinding
wheel (10).
9. Switch the device off and grind
the drill.
10. Switch the device off and wait
for the grinding wheel (10) to
stop.
11. Remove the drill holder (14)
and insert it into the rotatable
drill mount (11) by rotating in
by 180°. Using the same adjust-
ment, you can grind the opposite
cutting edge of the drill.
12. Switch the device off and grind
the drill.
13. Switch the device off and wait
for the grinding wheel (10) to
stop.
Sharpening picks
and chisels
1. Mount the selected sharpener
(see Mounting sharpener).
2. Place the blade on the tool table
(6) so that the end to be shar-
pened fits closely to the edge of
the tool table (6). The magnetic
holder (5) keeps the blade in
position.
3. For small picks, use the spacer
(4).
4. Select the angle according to the
existing bevel angle.
5. Release the retaining screw for
the angular adjustment (7) and
turn the tool table (6) into positi-
on.
6. Tighten the retaining screw for
angular adjustment (7) again.
7. Switch the device on and move
the tool table (6) equally back
and forth along the grinding
wheel (10).
8. Always use light pressure while
sharpening and slowly push
the blade towards the grinding
wheel (10).
9. Repeat the sharpening process
until all irregularities have been
removed.
10. Switch the device off and wait
for the grinding wheel (10) to
stop.
