2 PSBSA 18-Li A1
GB
IE
CY
CORDLESS HAMMER DRILL
PSBSA 18-Li A1
Introduction
Congratulations on the purchase of your
new appliance. You have selected a high
quality product. The operating instructions
are part of this product. They contain
important information on safety, usage
and disposal. Before using the product, familiarise
yourself with all operating and safety instructions.
Use the product only as described and for the
areas of application specifi ed. Please also pass
these operating instructions on to any future
owner(s).
Intended use
This appliance is intended for installing and re-
moving screws as well as drilling in wood, metal,
ceramic and plastic and impact drilling in bricks
and masonry. It is not suitable for impact drilling
in natural stone such as granite. The light on this
appliance is intended to illuminate the immediate
work area of the appliance.
Use this product only as described and for the
areas of applications specifi ed. The appliance is
not meant for commercial use. Any other usage
of or modifi cation to the appliance is deemed to
be improper usage and carries the risk of serious
personal injury. The manufacturer accepts no re-
sponsibility for damage(s) resulting from improper
usage.
Features
Speed selector
Rotational direction switch / Lock
ON/OFF switch / Speed control
Bit holder
Battery charge level button
Battery display LED
Battery pack
Release button for battery pack
LED work light
Additional handle
Chuck
Torque selection ring
Rapid charger
Red charge control LED
Green charge control LED
Package contents
1 Cordless hammer drill PSBSA 18-Li A1
1 Rapid charger PLG 18 A1
1 Battery pack
1 Additional handle
1 User manual
Technical data
Cordless hammer drill: PSBSA 18-Li A1
Rated voltage:
18 V
Drive: 2 speed drive
Idle speed: 1st gear: n
0
0–440 rpm
2nd gear: n
0
0–1650 rpm
Hammer frequency: 0–26400 /min
Max. torque: 40 Nm
Torque stages: 1–20 + 1 drill setting /
+ 1 hammer drill setting
Chuck clamping range: max. 13 mm
Recommended hole
diameters:
max. 13 mm for steel
max. 30 mm for wood
max. 15 mm for bricks
Battery: PAP 18 A1
Type:
LITHIUM ION
Rated voltage: 18 V
Capacity: 1.5 Ah
Rapid charger: PLG 18 A1
INPUT:
Rated voltage:
230–240 V ~, 50 Hz
Power consumption: 40 W
OUTPUT:
Rated voltage:
18 V
Charging power: 1.8 A
Charging time: approx. 60 min
Fuse (internal): 2 A T2A
Protection class: II /
