10 GB/IE/CY
or lack of experience and knowledge if they have
been given supervision or instruction concerning
use of the appliance in a safe way and under-
stand the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
The charger is only suitable for
indoor use.
Attention - Service lines!
Take steps to ensure that
you do not hit upon any service lines
(electricity, gas, water) when working
with electrical appliances. Check, if need be
with a service line detector, before you start to cut
or bore into a surface.
Original ancillaries /
accessories
Use only the ancillaries and accessories
that are detailed in the operating in-
structions. The use of ancillaries and acces-
sories other than those recommended in the
operating instructions could lead to an increased
risk of personal injury for you.
Before first use
Removing / charging / inserting
rechargeable battery pack
Note: The battery is supplied partially charged.
Charge the rechargeable battery in the charging
station for at least one hour before first use. By doing
this the battery will operate at its highest capacity.
You can charge the Li-Ion battery at any time with-
out risk of shortening battery life. Interrupting the
charging process does not damage the battery.
1. In order to remove the rechargeable battery pack
7 , press the release buttons 8 and take the
rechargeable battery pack 7 out of the device.
2. Insert the rechargeable battery pack 7 into the
quick-charger 14 .
3. Insert the mains plug into the mains socket.
The indicator LED 12 illuminates red.
4. The green charge indicator LED 13 shows you
that the charging process is complete and the
battery pack
7 is ready for use.
5. Insert the rechargeable battery pack 7 into
the device.
Checking the battery status
To check the battery status, press the button for
the rechargeable battery LED 2 (refer to main
diagram). The status or the remaining power
will be displayed in the rechargeable battery
LED
3 as follows:
RED / ORANGE / GREEN = maximum charge /
performance
RED / ORANGE = medium charge / performance
RED = low charge – recharge battery
Changing tools
Your cordless drill / screwdriver has a fully automat-
ic spindle lock
.
Once the motor has come to a halt, the drive shaft
is automatically locked, so that the chuck
11 can
be opened simply by turning it .
After you have inserted the required bit and fixed it
in place by turning the chuck
, you can immedi-
ately continue working. The spindle lock releases
itself automatically when the motor is started (by
operation of the ON / OFF switch
5 ).
2 Gear Drive
Note: Move the gear selector switch 1 only after
the device has come to a standstill.
