6 GB/IE/CY
Introduction / Safety information Introduction
Arc welder PESG 120 A1
Introduction
Congratulations! You have chosen a
high-quality device from our company.
Familiarise yourself with the product
before using it for the first time. In addition, please
carefully refer to the operating instructions and the
safety advice below. Initial operation of this tool
must be performed by trained personnel.
KEEP OUT OF THE REACH OF CHILDREN!
Intended use
This electric welding equipment is suitable for
manual arc welding using the appropriate coated
electrodes. Improper product handling can be dan-
gerous to persons, animals and objects. Only use
the welding shield with welding glass and protec-
tive glass overlay marked accordingly, and only for
welding. The welding shield is not suitable for laser
welding! Only use the product as described and
for the indicated purpose. Keep these instructions in
a safe place. When passing this product on to others,
please also include all the documents. Any use other
than the intended is prohibited and potentially dan-
gerous. Damages resulting from noncompliance or
misuse are not covered by the warranty and are not
included in the manufacturer‘s liability. This device
has been designed for household use and may not
be used for commercial or industrial purposes.
Parts description
Electric Welding Equipment
1 Handle
2 ON / OFF switch
3 Hand wheel
4 Earth terminal
5 Brush
6 Electrode holder
7 Overheating control lamp
Welding shield
8 Welding shield
9 Handle
10 Protective glass
Symbols / Technical Data
EN 60974-6 European standard on welding
equipment for manual arc welding
with limited duty cycle
50 Hz Mains frequency
U1 Mains voltage
I1 max maximum mains current rated value
U
0
Rated no-load voltage
I
2
Welding current
φmm Electrode diameter
I
1eff
Effective value of the highest mains
current (A)
t
w
(S) Average duty cycle (s)
t
r
(S) Average reset time (s)
IP21S Protection type
H Insulation class
Power input; phase number, as well as
1 ~ 50 Hz alternating current symbol and
rated value of the frequency
Do not dispose of electrical equip-
ment in the household waste. In ac-
cordance with European Directive
2002 / 96 / EC covering waste
electrical and electronic equipment
and its transposition into national
legislation, worn out electrical
