B • Lock / unlock the starting lever
(25) of the gun (1) by depressing
the locking knob (24).
Lock the starting lever (25) to
prevent the pressure cleaner
from being inadvertently / ac-
cidentally started.
Locked
Open
Interrupting operation
• Release the lever of the gun (1).
• During prolonged work intervals turn
off the pressure cleaner by its ON /
OFF switch (10).
If the equipment falls over,
switch off the equipment
immediately at the on/off
switch (6) and disconnect the
equipment from the mains at
the mains power cord. Risk
of electric shock! Only now
should the equipment be re-
turned to an upright position.
For your own safety, wait
approx. 5 minutes before re-
connecting to the electricity.
Ending operation
1. After having worked with a detergent
rinse the pressure cleaner with clear
water.
2. Release the lever of the gun (1).
3. Turn off the pressure by its ON / OFF
switch (6). Disconnect the mains plug.
4. Turn off the water tap.
5. Disconnect the pressure cleaner from
the water mains.
6. Pull the lever of the gun (1) to vent the
pressure existing within the system.
Using detergents
The pressure cleaner was designed for
operation with a neutral detergent based
on a biologically decomposable anionic
tenside. Other detergents or chemical sub-
stances could impair the safety of the pres-
sure cleaner and damage it. Such damage
to the equipment is not covered by the
guarantee.
Fill/drain detergent:
• To add cleaning agent to the jet, you
must first fill the cleaning agent tank
(17).
• To remove the cleaning agent tank
(17), hold it on the side and push it up-
wards. You can now pull the cleaning
agent tank out of the bottom and side
guides on the pressure cleaner. Mind
to first remove the induction hose and
the cap from the opening of the clean-
ing agent tank (16) as they will remain
on the pressure cleaner.
• To reinstall the cleaning agent tank
(17), trace back the above steps.
Working Instructions:
• Operate the standard Vario nozzle
(19) in low-pressure mode to automati-
cally add cleaning agent to the water.
• The rotating wash brush (20) is always
in low-pressure mode and cleaning
agent will thus always be added to the
water.
• If you want to use the rotating wash
brush (20) without cleaning agents, the
cleaning agent tank (17) suction hose
must be placed in an empty cleaning
agent tank or leading outside.
