6
GB IE CY
Before use, check that the blades
are sharp. Ensure that the blades are
sharpened whenever blunt, in order
to avoid overstressing of the ma-
chine. Damages caused by cutting
with blunt blades are not covered by
the guarantee.
General Description
See the front fold-out page for il-
lustrations.
Scope of delivery
Unpack the device and check it for com-
pleteness.
- Electric hedge trimmer
- Blade protection
- Instruction Manual
Overview
1 Contact protection guard with
predrilled holes for hanging the
trimmer up
2 Cutter bar
3 Hand protection
4 Loop grip with deadman switch
5 Vents
6 On/off switch
7 Tension relief
8 Grip
9 Mains cable
10 Blade protection
Function Description
The electric hedge trimmer is driven by an
electronic motor. The equipment is double-
insulated for safety and does not require
earthing.
The hedge trimmer is equipped with a
double-sided safety cutter bar. When cutting,
the blades move backwards and forwards
in linear motion. The impact protection on
the tip of the cutter bar prevents unpleasant
recoils should the trimmer come into contact
with walls, fences and so on.
The unit can only be operated with the
deadman switch depressed, in order to
protect the operator. In addition, the hand
guard protects against branches and briars.
Please note the following descriptions for the
function of the operating components.
Technical Data
Electrical Hedge Trimmer ............FHT 600 B2
Input voltage rating ..............230V~, 50 Hz
Input power................................... 600 W
Safety class ........................................ II
Protection category ............................IP 20
Knife movements per minutes .............2800
Weight ...........................................3.6 kg
Cutting length ...............................600 mm
Cutting capacity .............................24 mm
Blade cutting angle .......................38° ± 2°
Sound pressure level
(L
pA
) .................. 84.4 dB(A), K
pA
=3 dB(A)
Sound power level (L
wA
)
guaranteed .............................. 98 dB(A)
measured ...... 96.1 dB(A); K
wA
=1.9 dB(A)
Vibration (a
n
) at the
handle ............. 2.248 m/s 2 ; K=1.5 m/s 2
bow handle ..... 2.636 m/s 2 ; K=1.5 m/s 2
Noise and vibration values have been de-
termined according to the standards and
regulations mentioned in the declaration of
conformity.
Technical and optical changes may be
undertaken in the course of further develop-
ment without notice. All dimensions, refer-
ences and information in this instruction
