35
GB
For your safety: Stand behind the
device when starting it.
Check the petrol and oil levels regu-
larly (see “initial operation”) and
refill in time.
Cold start:
1. Press the petrol pump (32)
(primer) 3 x.
2. Pull the safety loop (2)
towards the grip handle
(1) and hold it.
3. Pull the starter handle (7).
4. If the motor starts slowly, release
the starter handle into the starter
rope-guide (3).
For a warm start it is not necessary
to press the primer (32).
If the primer is pressed too often,
too much petrol will enter the car-
burettor and the motor is difficult to
start.
Motor stop:
• Release the safety loop (2). The motor
switches off and the knife is braked.
Knife stopping device:
Regularly examine the knife stopping de-
vice:
Release the safety loop (2). The motor
switches off and the knife is braked. The
knife must stop within 7 seconds.
Mowing
1. Start the engine (see ).
2. Hold the grip handle (1) and the
safety loop (2) with both hands
while mowing.
Working Instructions
General Working Instructions
• As far as possible, mow the lawn when
it is dry in order to protect the turf.
• Set the cutting height such that the
equipment is not overloaded.
• Run the equipment at walking speed in
lines that are as straight as possible. For
uninterrupted mowing, the lines should
always overlap by a few centimetres.
• Do not move backwards.
• On slopes, always work across the
slope.
• If the blade comes into contact with
a foreign body, switch off the engine
immediately. Wait until the blade is
stationary and check the equipment for
damage. Restart work only if the equip-
ment is undamaged.
• Switch off the equipment during longer
breaks and for transportation and wait
until the blade is stationary.
• Clean the equipment after each use, as
described in the “cleaning and mainte-
nance“ chapter.
Setting the Cutting Height
The equipment has 5 positions for setting the
cutting height (25-75 mm):
1. Pull the lever (17) outwards and
push it to the desired position
(33).
2. Push the lever (17) back in.
