5 GB/IE
Setting the temperature limiter
The cartridge 11 in this unit has a temperature limiter.
This function is not activated in the factory (neutral
setting).
CAUTION! Change the temperature limiter
setting only after the tap has been installed.
Turn off the main water supply.
Remove the red / blue hot / cold label 8
carefully by a small flat screwdriver (see Fig. C).
Release the lock screw 7 by turning it anti-
clockwise using a hexagon socket screw key.
CAUTION! Do not take the screw completely
out; just loosen it until the control lever can be
easily taken off.
Take off the control lever.
Loosen the cartridge end ring
9 by hand,
then screw off the cartridge locking ring 10 by
using a pipe wrench.
Now pull the setting ring 12 upwards with the
help of a screwdriver.
Note: Do not remove the cartridge.
Place the setting ring in the desired position as
shown in Fig. D.
Tighten the cartridge locking ring 10 onto the
lever arm again by using a pipe wrench, then
tighten the cartridge end ring
9 by hand.
Place the control lever back on to the lever arm
and tighten the locking screw by turning it
clockwise using a hexagon socket screw key.
Press the red / blue hot / cold label 8 into the
opening.
Turn on the main water supply and check the
temperature limiter.
Maintenance and cleaning
Tap care and cleaning
Please note that sanitary fittings require special
care and attention. Therefore you should follow
the following advice:
Never use corrosive or alcohol-based materials
for cleaning, as these could damage the product.
Clean your fittings with clean water, mild detergent
and a soft cloth or leather only.
Screw out the mixer nozzle 5 at regular intervals
and remove lime deposits or foreign bodies.
Non-observance of the above care advice can be
expected to result in damage to the surface of the
fittings. In this event your rights under the warranty
may be invalidated.
Disposal
The packaging is wholly composed of
environmentally friendly materials that can
be disposed of at a local recycling centre.
Contact your local refuse disposal authority for more
details of how to dispose of your worn-out product.
Information
Potability of mains water
Find out about the potability of your mains water
supply. Your local water authority or water supply
company will be able to inform you.
The following general recommendations
apply to the potability of the water from
your pipework:
Let the water run freely for a short time if it has
been stagnating in the pipework for more than
four hours. Do not use any of this stagnant water
in the preparation of food or for drinking. This
applies particularly as far as babies and infants
are concerned. Failure to observe this advice
may result in risks to health. Fresh water can
be readily distinguished from stagnant as fresh
water is noticeably cooler.
Do not use stagnant water from chromium-
plated pipework for the preparation of food or
for drinking or for personal hygiene if you are
allergic to nickel. This water may contain high
quantities of nickel and trigger an allergic reaction.
