4 GB/IE
Connection hose: Approx. 70 cm, kink-
resistant, stainless steel,
G½“ (approx. 21 mm)
standard connection
Safety advice

DANGER OF
LOSS OF LIFE AND ACCIDENT
TO INFANTS AND CHILDREN!
Never leave children unsupervised with the
packaging materials. Danger of suffocation.
Keep out of the reach of children. It is not a toy.
To avoid the risk of injury!
CAUTION! RISK OF INJURY! Please
ensure that no parts are damaged and that all
parts are correctly assembled. Incorrect assembly
or fitting may lead to injury. Damaged parts can
adversely affect safety and proper function.

The wall holder 14 should not be used to attach
or support anything, as the fixings and the wall
holder
14 are designed to support only their
own weight.
CAUTION! RISK OF SCALDING! When
making the hot water setting please ensure that
the temperature of the water is not too high.
CAUTION! RISK OF SCALDING! The
temperature of the water in the shower can be
altered by adjusting the overhead shower head
5 and the hand shower head 6 . Please check
the water temperature before you enter the
water spray jet.
Avoid damage to property!

Assembly should only be carried out by an
experienced person!

CAUTION! WATER DAMAGE! Before
drilling, ensure that there are no water pipes
where you intend to drill.

Ensure the selected wall is suitable to support
the shower fixture before installation. Further
information is available from your authorised
dealer.

Ensure that all gaskets are correctly seated.

Please note that all the seals are wear parts
and therefore will require to be replaced from
time to time.

Examine the wall before installation and
choose suitable installation fixings. We have
supplied fixings suitable for an ordinary solid
masonry wall.
 Mounting
CAUTION! RISK OF INJURY! The edges
of the wall holder 14 are extremely sharp. Please
be careful when fitting it.
Note: For fixtures with a G¾“ (approx. 26.4 mm)
connection, please use an adapter with G¾“
(approx. 26.4 mm) interior threading and G½“
(approx. 21 mm) exterior threading. Adapters are
available at any home improvement or plumbing
shop.
Note: A 23 mm spanner is required for the instal-
lation of the shower hose and the connection hose
for the valve. Please do not use a pipe wrench!
1. Remove the cap from the wall mount 14 . Unscrew
the screws from each of the wall mounts 14
using a slotted head screwdriver. Push the wall
mount
14 from below over the shower bar 1
(see Fig. B).
2. Determine the desired height of the top wall
mount 14 on the shower bar 1 .

Tighten the screws so that the wall mount 14 is
fixed in place (see Fig. C).
3. Push the hand shower head holder 15 from
below over the shower bar 1 (see Fig. D).

When doing this ensure that the tightening
knob of the hand shower holder
15 is on the
left (see Fig. D).
4. Slide the second wall mount 14 from below on
to the shower bar 1 (see Fig. E).

Ensure that there is an adequate distance be-
tween the two wall mounts
14 and the hand
shower holder 15 . Bear in mind that the hand
