8 GB/IE
Information / Warranty and Service Assembly and operation / Maintenance and Cleaning / Disposal
8. Push the hand shower head holder 14 from
above over the shower rail 13 .
9. Select the desired height for the shower head
rail 1 by exending the shower rail 13 corre-
spondingly.
10. Drill the holes for the mounting plate 17 .
11. Insert wall plugs 16 into the drilled holes and at-
tach the mounting plate 17 using the screws 18 .
12. Push the covering rosette 19 over the back of the
shower head rail 1 .
13. Using the two socket screws 20 at the bottom of
the shower head rail 1 , attach the shower head
rail 1 to the mounting plate 17 . Next push the
plastic covers 15 over the socket screws 20 .
14. Push the covering rosette 19 over the mounting
plate 17 . Attach the upper part of the shower
rail 13 to the shower head rail 1 .
15. Insert one seal 2 in the swivel nut of the shower
head 3 and screw the shower head 3 to the
shower head rail 1 .
16. Insert the seal 2 in the conical end of the shower
hose 5 and attach this to the hand shower
unit 4 .
17. Insert one seal 2 in the socket screw of the
shower hose 5 and screw this to the thread
of the diverter 6 .
Operation
Note: If the tap has not been used for a longer pe-
riod, flush the pipes thoroughly to avoid stagnation
and build-up of residues.
After the initial commissioning, carefully check all
connections for leaks.
Check the operation of the fitting. To do so, swing
the handle 8 into all permissible positions.
Note: If the tap has not been used for a long pe-
riod, flush the pipes thoroughly to avoid stagnation
and build-up of residue.
Open the main water supply.
Lift the handle
8 and swing it up and down in
order to regulate the speed or temperature of
the water.
Hot water:
Swing the handle
8 to the left.
Cold water:
Swing the handle
8 to the right.
Note: When the mixer tap is open, pull the diverter
button upward in order to switch to the shower func-
tion.
Depress the diverter button in order to end the shower
function.
Maintenance and Cleaning
Please note that the Mixer Shower requires specific
cleaning and maintenance.
Therefore, please follow the instructions:
Do not use any limescale removing agents, acidic
cleaning agents or scouring agents of any kind.
Do not use corrosive or cleaning agents contain-
ing alcohol.
Dry your Mixer Shower with a cloth after every
use in order to avoid the build-up of any lime-
scale.
Clean your Mixer Shower with clean water, mild
detergent and a soft cloth or leather only.
Non-observance of the above care advice can be
expected to result in damage to the surfaces of the
product.
This will inevitably invalidate the guarantee.
Disposal
To protect it from any damage in transit, this tap is
delivered in secure packaging.
The packaging is made of environmentally
friendly materials. Please dispose of them
in an environmentally friendly way.
At the end of its life expectancy, do not dispose of
the product with the household waste.
Information regarding environmentally-friendly dis-
posal can be obtained from your municipal or city
administration.
