5 GB/IE
Hydraulic Bottle Jack
 Proper use
The hydraulic vehicle jack is intended for raising and
lowering motor vehicles. Other uses or modification
of the hydraulic vehicle jack shall be considered as
improper use and may lead to injury or damage.
The manufacturer will not accept liability for loss or
damage arising from improper use. The product is
not intended for commercial use.
Note: Reclose the release valve
5 after each use!
 Description of parts
1 Support plate
2 Extension screw
3 Lifting handle socket
4 Safety valve
5 Release valve
6 Lifting handle (for pump mechanism)
7 Rod (for release valve)
8 Oil plug
 Technical data
Stroke: approx. 18.5 - 36 cm
Maximum load: 3000 kg
Weight: approx. 3.1 kg
Hydraulic oil:
Complies with ISO VG 15
 Included items
1 Hydraulic vehicle jack
1 Lifting handle
1 Rod for release valve
1 Operating instructions
Safety notes
DANGER! Follow the instructions below to
avoid the threat of loss of life, injury, or damage
to the product etc.

Always use axle stands and wheel chocks in
addition to your hydraulic vehicle jack. Never
work under a raised vehicle unless you have
taken additional safety precautions. This is
intended to prevent the vehicle from rolling
away, sliding off or overturning the jack.

Use the product on a solid, level surface only.
Using the product on an unstable or uneven
surface – such as a gravel surface – may lead
to the load slipping.

3000
kg
Ensure that you never exceed the
allowable (rated) load capacity.

The person operating the jack must observe the
jack and the load during all movements.
 Never work under the raised load if it has not
been made secure by suitable means.

Do not allow the hydraulic vehicle jack to be
used by uninstructed or inexperienced persons.

Before using the hydraulic vehicle jack take
precautions to prevent the vehicle from rolling
away. Put the handbrake on, place the vehicle
in gear (with automatic gearboxes set to “P”)
and chock the wheels.

Even with safety measures in place always
remain alert and make a visual check that the
support plate
1 is firmly seated against the
vehicle jacking point.

Make sure that no petrol, battery acid or
any other dangerous substance can flow out of
the vehicle when the vehicle is being lifted.

Check that no person or object is under the
vehicle before you lower it.

Lower the vehicle slowly.

Check that all parts have been assembled and
fitted properly and are undamaged.

Before each use check that the hydraulic vehicle
jack is working properly. Check the screws and
valves of the hydraulic vehicle jack for correct
seating and look out for hydraulic oil leaks in
particular.
 Never use the hydraulic vehicle jack for mov-
ing or loading a vehicle. Never use it to lift a
whole vehicle completely off the ground.
 Make sure that no-one – especially a child
– is in the vehicle and that everyone is kept at
