10 GB/IE
of the solar cell is dependent on mounting
on a vertical wall.
2. Depending on the mounting height (ideally
at 2 m) the sensor 7 has a detection range
of max. 5m with a detection angle of 100°
horizontally and 90° vertically.
3. Be sure the sensor is not illuminated by street
lighting at night. This can influence the effect.
Fix the mounting plate 2 using the provided
rawlplugs 1 (ø 6 mm) and the provided
screws 3 . Ensure that the arrow on the mark-
ing of the mounting plate ( UP) is showing
vertically upward (Diagram A).
Note: The enclosed mounting material is
suitable for ordinary masonry construction.
Other wall substrates may require other fas-
tening materials. Seek specialist advice when
in doubt.
Set the ON / OFF switch 11 to the position
„ON“ to start the operation of the light
(Diagram G).
Note: In the „OFF“ position both the light
and the charging function are disabled.
Attach the device to the mounting plate in
such a way that the hangers
4 of the mount-
ing plate grip in the receivers 5 on the back
of the device. Slide the device downwards
until the hangers click into place in the receiv-
ers (Diagram B).
After mounting, check that the main unit is
fitted securely.
Replacing the
rechargeable batteries
Note: Regularly clean the sensor and solar cell
to ensure proper functionality (refer to „Clean-
ing and Care“).
Change the rechargeable batteries as follows:
Slide the device upwards until the hangers 4
release from the receivers 5 (Diagram B).
Remove the device from the wall
Set the ON / OFF switch 11 to position „OFF“
(Diagram G).
