LSHB 150 A1

GB

IE

Appliance description

Rotary switch LUX

2

Rotary switch TIME

3

Rotary switch SENS

4

Motion

Detector

5

Bracket

6

Protective

screen

7

Screw

8

Bulb

9

Cable

entry

10

Locking

screw

Assembly / Electrical connection

Selecting the installation location

The appliance can be mounted indoors or in a covered outdoor area.

DANGER

Maintain a suffi cient distance from the illuminated area (at least 1 m),
otherwise there is a risk of fi re from the generated heat.

The motion detector

4

may be oriented at about 170° horizontally and about

180° vertically and has a detection range of max. 120°.

The range is adjustable from about 5 - 12 m.

When selecting the installation location ensure there will be no adverse incidents
registered in the coverage range, such as from roads or lights.
